Rittal 8617120 VX System-Chassis 23 x 64 mm W x H x D: 500 mm
|
40,60 EUR 41,13 EUR |
|
|
( 48,31 EUR incl. VAT ) ≈ £33.98 | ≈ $44.62 plus delivery charges: 55,00 € |
|
| Delivery time from supplier's stock (ca.) 3 workdaysinfo_outline | |
| In Stock: 4 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 1349781 |
| Mfg Part No: | 8617120 |
| UPC/EAN: | 4028177829121 |
| Weight: | 1.98 kg |
| Type: | VX 8617.120 |
Product information for Rittal 8617120:
Applications
The system chassis is intended for use in various enclosure types, particularly in enclosures with a depth, width, or height of 500 mm. It is compatible with enclosure types VX, VX IT, VX SE, AX, and AX plastic. For AX enclosures, mounting requires the use of the AX interior fitting rail and the AX base fitting rail. For AX plastic enclosures, the universal angle is required. For VX SE enclosures, the adapter rail for VX compatibility is necessary. The chassis can also be mounted in CX console sub-units with an enclosure depth of 500 mm. For VX plinths, mounting is possible on the plinth corner pieces when the plinth width or depth is 600 mm.
Functions and Equipment in Detail
The chassis features a system perforation on all four sides, enabling flexible mounting into the existing enclosure structure. The perforation is designed so that the chassis can be simply inserted into the pre-drilled holes and screwed in place. The top and bottom edges of the chassis are equipped with additional perforations for cage nuts, allowing custom components such as switches, connectors, or small devices to be fastened using metric screws. The material choice of galvanized sheet steel ensures high mechanical stability and corrosion resistance, which is important for use in industrial environments.
Technology Explained Simply
The system perforation is a standard feature in Rittal enclosures and enables modular and flexible mounting of components. The chassis fits into this perforation and is fixed with screws, ensuring a stable fastening. The cage nuts at the top and bottom edges serve as mounting points for additional components that do not fit directly into the system perforation. The galvanized surface protects the sheet steel from corrosion, which is particularly beneficial in damp or aggressive environments. The dimensions of 23 x 64 mm are aligned with the standard sizes of Rittal systems to ensure universal usability.
Compatibility and Accessories
The chassis is suitable for a variety of enclosure types, including VX, VX IT, VX SE, AX, and AX plastic. For AX enclosures, the use of the AX interior fitting rail and the AX base fitting rail is required. For AX plastic enclosures, the universal angle is necessary. For VX SE enclosures, the adapter rail for VX compatibility is needed. The chassis can also be mounted in CX console sub-units with a depth of 500 mm. For VX plinths, mounting is possible on the plinth corner pieces when the plinth width or depth is 600 mm. Suitable accessories include cable ties with a length of 150 mm and the universal angle for AX plastic, which support mounting and cabling.
Mounting and Installation
Mounting is done by inserting the chassis into the system perforation of the enclosure frame and then screwing it in place. The system perforation is present on all four sides, enabling flexible positioning. Fastening is done using the fastening material included in the delivery. The cage nuts at the top and bottom edges can be used to fasten additional components. Mounting is simple and requires no special tools, except a screwdriver or screw clamp. The use of appropriate adapter or rail components is required for certain enclosure types to ensure compatibility.
Advantages in Operation
The system chassis offers a flexible and modular solution for the interior fitting of enclosures. The simple mounting by inserting and screwing reduces installation time. The system perforation on all four sides enables versatile placement within the enclosure. The integrated cage nuts at the top and bottom edges facilitate the fastening of additional components. The galvanized surface ensures high corrosion resistance, extending the service life of the chassis. Compatibility with various enclosure types increases operational flexibility and reduces the need to stock different chassis for different enclosure types. The packaging unit of 4 pieces enables economical procurement for larger projects.
| General | |
| Material | steel sheet |
| Surface protection | Zinc-plated |
| Scope of delivery | Including mounting hardware |
| Mounting options VX | In cabinet depth 500 mm, on inner mounting plane |
| Mounting options VX SE | In cabinet depth 500 mm, on the inner mounting plane, in combination with the adapter rail for VX compatibility |
| Mounting options AX | Housing width/height 500 mm, in combination with the rail for indoor installation AX and floor installation rail for AX |
| Mounting options AX stainless steel | In cabinet width/height 500 mm, in combination with the floor mounting rail |
| Mounting options AX plastic | In housing width 500 mm, in combination with universal bracket |
| Mounting options CX | In cabinet base unit with housing depth 500 mm |
| Mounting options VX socket | In base width/depth 600 mm when mounted on base corner pieces |
| Suitable for | Enclosure type: VX, VX IT, VX SE, AX, AX plastic; Suitable for width or height or depth: 500 mm |
| PCF/VE (Cradle-to-Gate) | 10,8 |
