Rittal 8619500 VX swing frame, small, for W: 600/800 mm

Your rating:
Average rating
product review for Rittal 8619500 VX swing frame, small, for W: 600/800 mm
( 4.5 / 5 ) 12 ratings
Rittal 8619500
This image may differ from the desired article.
Rittal 8619500Rittal 8619500Rittal 8619500Rittal 8619500
74,64 EUR
( 88,82 EUR incl. VAT )
≈ £62.47  |  ≈ $82.03
plus delivery charges: 55,00 €
Delivery time from supplier's stock (ca.) 12 workdaysinfo_outline
In Stock: >10 pieces
1x Rittal 8619500 VX swing frame, small, for W: 600/800 mm
Datasheet:file_download Download
Lieske Part No.:1441174
Mfg Part No: 8619500
UPC/EAN: 4028177919563
Weight:2.681 kg
Type:VX 8619.500

Product information for Rittal 8619500:

The Rittal VX 8619.500 is a swing frame, small, specifically designed for mounting 482.6 mm (48,3 cm ( 19 inch ))-installation components in enclosures of the VX, VX SE and AX series. It enables flexible installation of devices mounted in a vertical enclosure profile, with the frame being swivellable by 130°. The construction made of sheet steel with zinc-coated surface provides a robust and corrosion-resistant base for use in industrial environments. The product is designed for enclosures with a width of 600 mm or 800 mm and requires a minimum height of 380 mm. The height of the frame corresponds to 3 height units (HE), which matches the standard dimensioning in the IT and electrical industry.

Applications

The swing frame is intended for use in enclosures of the Rittal series VX, VX SE and AX. It is particularly suitable for applications where flexible accessibility to mounted devices is required, such as in process automation, machine control or operator panels. The width variants of 600 mm and 800 mm cover common standard sizes, making the frame usable in many industrial enclosure configurations. The minimum height of 380 mm ensures that the frame can be mounted in sufficiently high enclosures without restricting the swivelling motion.

Functions and Equipment in Detail

The delivery includes 2 hinges with a 130° opening angle, a latch with double-bar lock insert, and the materials for mounting to the mounting kit. The hinges enable secure and precise swivelling, with the 130° angle providing sufficient space for access to mounted components. The latch with double-bar lock insert ensures secure locking of the frame in the closed position. The mounting materials are intended for installation on the mounting kit, with the exact mounting method depending on the specific enclosure construction.

Technology Explained Simply

The swing frame serves as a mounting base for 48,3 cm ( 19 inch ) devices installed in an enclosure. The 130° swivelling motion allows the devices to be rotated forward, making them accessible for maintenance, configuration or diagnostics. The zinc coating of the sheet steel construction protects against corrosion, which is especially important in humid or industrial environments. The use of sheet steel ensures high mechanical stability and load capacity. The 3 HE height corresponds to a standard dimension widely used in the IT and electrical industry, enabling the mounting of standard 48,3 cm ( 19 inch ) devices.

Compatibility and Accessories

The swing frame is suitable for enclosure types VX, VX SE and AX. When installing in AX enclosures, the AX mounting kit is additionally required. In VX SE enclosures, the frame is mounted to the enclosure profile in conjunction with the VX adapter rail. Depending on the expansion situation, system chassis 23 x 64 mm may be required to enable mounting. Compatibility with the mentioned enclosure types and accessories ensures flexible integration into existing systems.

Mounting and Installation

Mounting is carried out on the mounting kit of the respective enclosure. In VX SE enclosures, the frame is fastened to the VX adapter rail. The mounting materials included in the delivery are for secure anchoring to the enclosure profile. The exact mounting instructions are described in the manufacturer's data sheet, with the instructions applying to the respective enclosure construction.

Advantages in Operation

The swing frame provides flexible accessibility to mounted devices without having to open the entire enclosure. The 130° swivelling motion enables safe and convenient access, making maintenance and service work more efficient. The zinc coating of the sheet steel construction ensures long service life, even in demanding environments. Compatibility with various enclosure types and accessories increases flexibility in system planning. Mounting is simple and does not require special tools, enabling quick and reliable installation.

General
Materialsteel sheet
Surface protectionZinc-plated
Scope of delivery2 hinges 130°, including strike plate with double-bolt lock insert, material for mounting on installation kit
NoteTo lock the opened swivel frame, the swivel frame locking mechanism is required. Depending on the installation situation, system chassis 23 x 64 mm are required. In VX SE on cabinet profile in combination with adapter rail VX. For further installation options, see "Technology in detail".
Note on part numberFor installation in AX, additional installation kit AX required
Suitable forCabinet type: VX, VX SE, AX, width: = 600 mm, = 800 mm, height: ≥ 380 mm
Suitable for housing typeVX, VX SE
Height units3 HE


Product data sheet
Datasheet for Rittal 8619500, EAN: 4028177919563
