Rittal 7979723 PDU surge protection, rated power: 11 kW, rated current: 50 A,
|
218,73 EUR |
|
|
( 260,29 EUR incl. VAT ) ≈ £183.08 | ≈ $240.38 plus delivery charges: 55,00 € |
|
| Delivery time from supplier's stock (ca.) 12 workdaysinfo_outline | |
| In Stock: >50 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 1775587 |
| Mfg Part No: | 7979723 |
| UPC/EAN: | 4028177948549 |
| Weight: | 2.52 kg |
| Type: | DK 7979723 |
Product information for Rittal 7979723:
Applications
This overvoltage protection module is universally applicable in installations containing sensitive electronic components, such as IT infrastructures, servers, network devices, or industrial control systems. It is particularly suitable for TN-S networks, commonly used in industrial and commercial electrical engineering. Mounting on the enclosure frame allows flexible positioning within the enclosure, with the compact design measuring 44 mm (width), 75 mm (height), and 250 mm (length), requiring minimal space. Use in combination with other overvoltage protection stages (type 1 and type 2) is required to ensure a complete protection chain.
Functions and Equipment in Detail
The module features a potential-free alarm contact that can transmit status messages to higher-level systems, such as building automation (BAS). This enables centralized monitoring of the protection module and early response in case of faults. Additionally, an optical status monitoring indicator is integrated directly into the surge arrester, visually displaying the operating status. The maintenance-friendly design uses a plug-in system, allowing replacement of the surge arrester without interrupting the power supply. This increases system availability and reduces downtime.
Technology Explained Simply
The type 3 overvoltage protection operates as the final stage in the protection chain and responds to voltage surges that were not fully absorbed by previous stages (type 1 and type 2). The technology used is based on surge arresters that activate during overvoltage and divert the energy to ground. The housing material consists of an aluminum extruded profile, anodized to resist corrosion and mechanical stress. The color RAL 9005 (black) ensures uniform visual appearance in technical enclosures. Compliance with standards IEC 61 643-11 and EN 61 643-11, as well as directives Low Voltage Directive 2014/35/EU and EMC Directive 2014/30/EU, guarantees conformity with European safety and EMC requirements.
Compatibility and Accessories
The module is designed for use in 3-phase systems and can be combined with other overvoltage protection modules of types 1 and 2 to form a complete protection chain. The connection cables H05VV-F5G2.5 are suitable for use in electrical installations and ensure a secure and reliable connection. The delivery includes the mounting hardware required for installation on the enclosure frame.
Mounting and Installation
Mounting is done directly onto the enclosure frame, secured using the included mounting hardware. The pre-fabricated connection cables simplify installation, as no additional cabling work is required. The connection is made via CEE plug/coupling, ensuring a secure and standardized electrical connection. Installation is quick and can be done without special tools.
Operational Advantages
Operation of the overvoltage protection module is maintenance-friendly and reliable. The optical status indicator and alarm contact enable continuous monitoring. Replacement in case of failure can be done without interrupting the power supply, increasing system availability. The compact design and universal applicability make the module a flexible solution for various application scenarios in electrical engineering and IT infrastructure.
| General | |
| Model | Surge protection Type 3 |
| Material | Aluminium extruded profile, anodized |
| Colour | RAL 9005 |
| Scope of delivery | Including mounting hardware |
| Nominal power | 11 kW |
| Electrical connection type | CEE plug/coupler |
| Rated current (max.) | 16 A |
| Policies | Low Voltage Directive 2014/35/EU, EMC Directive 2014/30/EU |
| Standards | IEC 61 643-11, EN 61 643-11 |
| Width | 44 mm |
| Height | 75 mm |
| Length | 250 mm |
| Input cable connection (type/length) | H05VV-F5G2.5, 1 m |
| Connection output cable (type/length) | H05VV-F5G2.5, 1 m |
Questions & answers
What is the delivery time of Rittal 7979723 PDU surge protection, rated power: 11 kW, rated current: 50 A, ?
The article Rittal 7979723 PDU surge protection, rated power: 11 kW, rated current: 50 A, is currently in stock
According to our experience the article is ready for dispatch within 12 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Rittal 7979723 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Rittal 7979723 PDU surge protection, rated power: 11 kW, rated current: 50 A, always at the best possible price. We can give you a discount of 2% on Rittal 7979723 PDU surge protection, rated power: 11 kW, rated current: 50 A, if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
