Rittal 8001223 VX base plate, width: 800 mm, depth: 275 mm
|
-10% 15,41 EUR 17,19 EUR |
|
|
( 18,34 EUR incl. VAT ) ≈ £12.90 | ≈ $16.94 plus delivery charges: 55,00 € |
|
| Delivery time from supplier's stock (ca.) 12 workdaysinfo_outline | |
| In Stock: >100 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 1714126 |
| Mfg Part No: | 8001223 |
| UPC/EAN: | 4028177948785 |
| Weight: | 2.6 kg |
| Type: | VX 8001223 |
Product information for Rittal 8001223:
Applications
The base plate is used to seal the lower area of enclosures while enabling structured cable and conduit routing. It is particularly suitable for installations requiring organized cable management and equipotential bonding. It is used in industrial environments where safe and maintenance-friendly installation of electrical and electronic components is prioritized.
Functions and Equipment in Detail
The plate is equipped with earthing points and mounting elements to ensure secure equipotential bonding. This is important for dissipating electrostatic charges and enhancing electrical safety within the enclosure. Mounting is done via designated mounting points, and the delivery includes fastening material. The use of sliding plates is required to achieve complete sealing of the base opening. For double-door enclosures, one packaging unit is sufficient to supply one half of the enclosure.
Technology Explained Simply
The base plate is made of steel sheet protected against corrosion by zinc coating. The zinc-coated surface ensures longer service life, especially in humid or aggressive environments. The dimensions of 690 mm width and 275 mm depth fit exactly into enclosures with a width of 800 mm. The integrated earthing points allow for a secure connection to the protective conductor, which is essential for complying with electrical safety standards. The mounting elements are designed to ensure stable installation without damaging the enclosure structure.
Compatibility and Accessories
The base plate is compatible with enclosure types VX, VX IT, VX SE, CX console stand, and CX console base, provided the enclosure width is 800 mm. Use in double-door enclosures requires no additional measures, as one packaging unit is sufficient to supply one half of the enclosure.
Mounting and Installation
Installation is done by fastening to the designated mounting points in the enclosure. The included fastening material enables easy and secure installation. The base plate is positioned in the lower area of the enclosure, with cable entries aligned according to the arrangement of the conduits. The earthing points must be directly connected to the enclosure housing to ensure effective equipotential bonding.
Operational Advantages
The base plate provides a structured and secure solution for cable routing in the lower area of the enclosure. The integrated earthing points enhance electrical safety and facilitate compliance with standards. The zinc-coated surface ensures high corrosion resistance, extending the product's service life. Easy mounting and a clear delivery scope reduce installation effort and ensure reliable operation.
| General | |
| Material | steel sheet |
| Surface protection | Zinc-plated |
| Scope of delivery | Including mounting hardware |
| Note | To completely close a floor opening, at least one sliding plate is required. For double-door cabinets, one unit is sufficient for one cabinet half. |
| Width | 690 mm |
| Depth | 275 mm |
| Suitable for | Cabinet type: VX, VX IT, VX SE, CX console, CX console base, width: = 800 mm |
Questions & answers
What is the delivery time of Rittal 8001223 VX base plate, width: 800 mm, depth: 275 mm?
The article Rittal 8001223 VX base plate, width: 800 mm, depth: 275 mm is currently in stock
According to our experience the article is ready for dispatch within 12 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Rittal 8001223 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Rittal 8001223 VX base plate, width: 800 mm, depth: 275 mm always at the best possible price. We can give you a discount of 2% on Rittal 8001223 VX base plate, width: 800 mm, depth: 275 mm if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
