Rittal 5301325 VX IT tilt protection for VX IT sheet metal, RAL 3001
|
-10% 138,58 EUR 154,59 EUR |
|
|
( 164,91 EUR incl. VAT ) ≈ £115.99 | ≈ $152.30 plus delivery charges: 55,00 € |
|
| Delivery time from supplier's stock (ca.) 12 workdaysinfo_outline | |
| In Stock: >10 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 1910585 |
| Mfg Part No: | 5301325 |
| UPC/EAN: | 4028177952461 |
| Weight: | 3.22 kg |
| Type: | VX 5301325 |
Product information for Rittal 5301325:
Applications
The tilt protection is intended for use in industrial environments where enclosures are often placed on wheels or where permanent floor fixation is not possible. It is particularly suitable when frequent access to front-mounted or pulled-out components is required, for example during maintenance work or installation of front units. The conspicuous paint finish in RAL 3001 (Signal Red) ensures high visibility and reduces the risk of tripping hazards.
Functions and equipment in detail
The tilt protection is made of sheet steel, coated with paint, and is delivered in the color RAL 3001 (Signal Red). It is mounted on the enclosure frame, and installation is possible without a base structure. Mounting is tool-free and quick, achieved by snapping the feet onto the vertical profiles of the cabinet frame. Leveling is adjusted according to the cabinet height, ensuring stable positioning. The leveling tilt protection feet are designed for maximum load: a pull-out weight of 200 kg with a center of gravity located 250 mm in front of the enclosure front. This value is critical for safety when mounting or removing heavy components.
Technology explained simply
The functionality is based on increasing the footprint of the enclosure. By extending outward, the tipping moment is reduced, which occurs when weight is pulled out from the front area of the cabinet. The feet are designed to adapt to the respective cabinet height, thus forming a flat, stable base. The tool-free mounting enables flexible use — the tilt protection can be retrofitted at any installation site and removed again if needed.
Compatibility and accessories
The tilt protection is specifically developed for the enclosure type VX IT. It can be mounted on the enclosure frame without a base structure, but also in combination with leveling feet or a plinth up to a height of 200 mm. Compatibility with existing leveling feet allows flexible integration into existing installations.
Mounting and installation
Mounting is simple and quick: with the front door open, the tilt protection feet are snapped onto the vertical profiles of the cabinet frame. Subsequently, the height of the feet is leveled according to the cabinet height. The tool-free quick mounting enables flexible use without requiring additional tools. Installation is also possible on already installed cabinets, as no drilling or permanent modifications to the enclosure are required.
Advantages in operation
The tilt protection provides a safe and flexible solution for stabilizing VX IT enclosures. The tool-free mounting and easy removal increase operational flexibility. The load capacity of 200 kg with a center of gravity 250 mm in front of the front enables safe mounting or removal of heavy components. The Signal Red paint finish increases visibility and reduces accident risks. Compatibility with existing leveling feet and plinths up to 200 mm height expands application possibilities.
Scope of delivery
The scope of delivery includes 2 leveling tilt protection feet with tool-free quick mounting. No additional components, instructions, or tools are included.
| General | |
| Material | Sheet steel, painted RAL 3001 (Signal red) |
| Scope of delivery | 2 adjustable anti-tilt feet, with tool-free quick mounting |
| Load capacity | Max. extraction weight: 200 kg, centre of gravity 250 mm in front of housing front |
| Suitable for | Housing type: VX IT |
| PCF/VE (Cradle-to-Gate) | 24.5 kg CO2 eq (Cat B) |
| Note on PCF class | Category B: PCF value (Cradle-to-Gate) approximately calculated based on product weight and self-declared |
