Rittal 8617100 VX system chassis 23 x 64 mm W x H x D: 300 mm
|
34,27 EUR |
|
|
( 40,78 EUR incl. VAT ) ≈ £28.68 | ≈ $37.66 plus delivery charges: 55,00 € |
|
| Delivery time from supplier's stock (ca.) 12 workdaysinfo_outline | |
| In Stock: >10 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 1441094 |
| Mfg Part No: | 8617100 |
| UPC/EAN: | 4028177829107 |
| Weight: | 1.118 kg |
| Type: | VX 8617.100 |
Product information for Rittal 8617100:
Applications
The system chassis is intended for use in various enclosure types: VX IT, VX SE, and AX. It enables flexible mounting within the enclosure structure, with installation options varying depending on the enclosure type. In VX SE enclosures, it can be mounted at a depth of 300 mm on the inner mounting plane, requiring an adapter rail for VX compatibility. For AX enclosures, it is usable at a width or height of 300 mm, requiring the inner mounting rail for AX and the base mounting rail for AX. For AX stainless steel enclosures, mounting is also possible at 300 mm width or height, but only in combination with the base mounting rail. In the VX plinth system, the chassis can be mounted at a plinth width or depth of 300 mm onto the plinth trim panels, requiring plinth mounting angles. For a plinth width or depth of 400 mm, mounting is possible on the plinth corner pieces.
Functions and Equipment in Detail
The chassis features system perforation on all four sides, enabling flexible mounting. At the top and bottom, special perforations for cage nuts are integrated, allowing users to mount their own components using metric screws. Installation is performed by simply hanging the chassis into the system perforation and then securing it with screws. The zinc-coated surface provides good corrosion protection, which is particularly advantageous in industrial environments.
Technology Explained Simply
The system chassis is a modular component integrated into existing enclosure structures to create additional mounting surfaces. The use of cage nuts enables secure and quick mounting of electrical or electronic assemblies. The choice of material, zinc-coated sheet steel, ensures sufficient mechanical stability and durability under industrial conditions. The installation width of 300 mm is a standard size commonly found in many enclosure configurations, making the chassis highly compatible.
Compatibility and Accessories
The chassis is specifically designed for enclosure types VX IT, VX SE, and AX. It is not intended for other enclosure types. As suitable accessories, a cable tie L150 mm is offered, which can be used to secure cables or wiring inside the enclosure.
Mounting and Installation
Installation is performed by hanging the chassis into the existing system perforation of the enclosure frame. It is then secured using the mounting hardware included in the delivery. The installation is tool-assisted and requires no special tools other than a screwdriver or pliers. Positioning is on the inner mounting plane, with exact placement depending on the enclosure configuration.
Advantages in Operation
The system chassis offers a flexible and modular solution for the interior fitting of enclosures. The integrated system perforation and cage nut perforations enable quick and secure mounting of components. The use of zinc-coated sheet steel ensures high mechanical strength and corrosion resistance. Compatibility with various enclosure types and modular design increases flexibility in planning and reconfiguring enclosure systems. The inclusion of mounting hardware reduces additional purchasing effort and accelerates installation preparation.
| General | |
| Material | steel sheet |
| Surface protection | Zinc-plated |
| Scope of delivery | Including mounting hardware |
| Mounting options VX SE | In cabinet depth 300 mm, on the inner mounting plane, in combination with the adapter rail for VX compatibility |
| Mounting options AX | In housing width/height 300 mm, in combination with the rail for indoor installation AX and floor installation rail for AX |
| Mounting options AX stainless steel | In enclosure width/height 300 mm, in combination with the floor mounting rail |
| Mounting options VX socket | In base width/depth 300 mm on base panels, in combination with base mounting angles, in base width/depth 400 mm when mounted on base corner pieces |
| Suitable for | Cabinet type: VX IT, VX SE, AX, Suitable for width or height or depth: 300 mm |
| PCF/VE (Cradle-to-Gate) | 5,72 |
