Rittal 3235450 EC speed controller for speed regulation

Your rating:
Average rating
product review for Rittal 3235450 EC speed controller for speed regulation
( 4.5 / 5 ) 124 ratings
Rittal 3235450
This image may differ from the desired article.
65,90 EUR
( 78,42 EUR incl. VAT )
≈ £55.16  |  ≈ $72.42
plus delivery charges: 55,00 €
Delivery time from supplier's stock (ca.) 12 workdaysinfo_outline
In Stock: >100 pieces
1x Rittal 3235450 EC speed controller for speed regulation
Datasheet:file_download Download
Lieske Part No.:124873
Mfg Part No: 3235450
UPC/EAN: 4028177696617
Weight:0.202 kg
Type:SK 3235450

Product information for Rittal 3235450:

NTC sensor for temperature-dependent speed control of EC fans to reduce noise and save energy. Activation and power supply via an EC fan-and-filter unit.
Technical specifications: Control characteristic: fixed setpoint at 35°C, with linear control range between +35°C (maximum speed 100%) and +20°C (minimum speed 10%)
Protection category IP to IEC 60 529: IP 40
Supply includes: External sensor with connection cable (length 3 m)
Packs of: 1 pc(s).
EAN: 4028177696617
Customs tariff number: 90330000
eCl@ss 5.1: 27180792
eCl@ss 7.0: 27210707
ETIM 6.0: EC000256

Rated operating voltage: 10 V - 12 V (DC)
Temperature range: Operation (environment): -25°C...+80°C
Weight/pack: 0.2 kg
To fit Model No.: 3240.500
3241.500
3243.500
3244.500
3245.XXX
3140.500
3140.510

General
Technical dataControl characteristic: fixed setpoint at 35 °C, with linear control range between +35 °C (maximum speed 100 %) and +20 °C (minimum speed 10 %)
Scope of deliveryExternal sensor probe with connection cable (length 3 m)
Rotational speed100 %
Suitable for part no.3240.500/.900, 3241.500/.900, 3243.500/.900, 3244.500/.900, 3245.xxx, 3140.500, 3140.510, 3245.8x0
Operating temperature range-25 °C...80 °C
Rated operating voltage10 V - 12 V (DC)
Degree of protection IP according to IEC 60 529IP 40


Product data sheet
Datasheet for Rittal 3235450, EAN: 4028177696617

Questions & answers

What is the delivery time of Rittal 3235450 EC speed controller for speed regulation?

The article Rittal 3235450 EC speed controller for speed regulation is currently in stock

According to our experience the article is ready for dispatch within 12 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Rittal 3235450 to our sales team for an exact delivery time.

How can I buy the item at a lower price?

We offer you Rittal 3235450 EC speed controller for speed regulation always at the best possible price. We can give you a discount of 2% on Rittal 3235450 EC speed controller for speed regulation if you choose payment in advance on ordering.

We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
