Rittal 8004000 VX bayed enclosure system, 2-door, W x H x D: 1000x2000x400 mm,
|
820,08 EUR |
|
|
( 975,90 EUR incl. VAT ) ≈ £686.41 | ≈ $901.27 plus delivery charges |
|
| Delivery time from supplier's stock (ca.) 6 workdaysinfo_outline | |
| In Stock: >25 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 1440736 |
| Mfg Part No: | 8004000 |
| UPC/EAN: | 4028177813526 |
| Weight: | 151.8 kg |
| Type: | VX 8004.000 |
Product information for Rittal 8004000:
Applications
This enclosure system is intended for use in industrial plants, such as machine building, manufacturing systems, or automation technology. The protection rating IP 55 according to EN 60 529 ensures protection against dust and splashing water, making it suitable for indoor use in environments with increased contamination risk or occasional precipitation. The protection ratings NEMA 1 and NEMA 12, as well as the type rating according to UL 50E (Type 1, Type 12), confirm suitability for indoor environments and areas with light contamination. The IK code IK10 indicates high mechanical resistance against impact, making the enclosure system suitable for environments with mechanical stress.
Functions and Equipment in Detail
The enclosure system is supplied with an enclosure frame, two doors, a roof plate, a rear panel, divided base plates, a mounting plate, and two mounting rails 18 x 39 mm. The doors are equipped with a PU foam seal to ensure a tight seal. The lock door is mounted on the right side and can be reconfigured for left-side mounting. It features a four-point locking bar lock with a double bar insert according to DIN 43668. The secondary door is additionally secured with a double locking swing lever. The hinges are fitted with non-removable hinge pins, and the door opening angle is 130°, with a tool-free extension to 180° possible. The clearance from the floor is 17 mm.
Technology Explained Simply
The mounting plate is C-bent on the sides and is depth-adjustable in 25 mm increments via integrated plastic glides and reusable mounting rails. It features an integrated mounting grid to simplify component positioning. The base plates are divided into three sections, removable, and replaceable, allowing flexible adaptation to different mounting conditions. The rear panel and roof plate are equipped with PU foam seals and are removable, enabling easy maintenance and cleaning. The rear panel includes a positioning aid, and the roof plate is mounted using M12 fastening screws.
Compatibility and Accessories
The enclosure system is expandable with various accessories. Compatible accessories include levelling feet M12 with an adjustment height of 18–43 mm, C-profile rails, dust protection strips, mounting brackets for internal and external mounting levels, transport eyes, circuit diagram pockets, base plates in various depths, mounting plate spacers, comfort handles, side panels, cable entry ferrules in various diameters, multi-point locking mechanisms, plug-through ferrules, and a multitool. These components allow for individual adaptation of the enclosure to specific requirements.
Installation and Mounting
Mounting is performed via the integrated base frame with base reinforcement, enabling secure fastening to the floor. The enclosure’s load capacity is up to 15,000 N. The mounting plate is depth-adjustable, and the mounting rails are reusable. The rear panel, roof plate, and base plates are electrically conductive to the frame, ensuring automatic equipotential bonding in accordance with DIN 62 208. The electrical connection enables safe earthing and is prepared for additional earthing straps.
Operational Advantages
The enclosure system offers high mechanical stability and protection through IP 55 and IK10 ratings. The modular construction with two mounting levels enables space-saving and rapid internal installation. The depth-adjustable mounting plate and reusable mounting rails increase installation flexibility. The removable doors, rear panel, and roof plate facilitate maintenance and inspection. The integrated 25 mm grid perforation and M6 blind rivet nuts offer versatile mounting options for components and accessories.
Materials and Surface
The enclosure system is made of sheet steel in various thicknesses: enclosure frame, roof, rear panel, and base plates from 1.5 mm sheet steel, doors from 2.0 mm sheet steel, and the mounting plate from 3.0 mm sheet steel. The surface of the enclosure frame is dip-primed, while doors, roof, and rear panel are dip-primed and externally powder-coated with a textured finish in RAL 7035. The mounting plate and base plates are galvanized. The RAL 7035 color is a gray, textured finish typical for industrial applications.
Certifications and Standards
The enclosure system complies with standards EN 60 529 IP 55), NEMA 1 and NEMA 12, UL 50E (Type 1, Type 12), and is certified with IK code IK10. Approvals include Bureau Veritas, DNV, Lloyds Register, and UL + C-UL (listed). The surface treatment meets requirements for electrical conductivity and equipotential bonding according to DIN 62 208.
Environment and Sustainability
The product life cycle (Cradle-to-Gate) has a PCF value of 413.95 kg CO2 eq (Category B). This value is approximately calculated based on product weight and self-declared. Manufacturing takes environmental standards into account, with materials and processes meeting industry requirements.
| General | |
| Material | Cabinet frame: steel sheet, 1.5 mm, roof: steel sheet, 1.5 mm, door: steel sheet, 2.0 mm, rear panel: steel sheet, 1.5 mm, base plates: steel sheet, 1.5 mm, mounting plate: steel sheet, 3.0 mm |
| Surface protection | Cabinet frame: dip-primed, door, roof and rear panel: dip-primed, externally powder-coated, textured lacquer, mounting plate and base sheets: galvanised |
| Colour | RAL 7035 |
| Scope of delivery | cabinet frame, door(s), door hinge right, reversible to left, roof sheet, rear panel, floor sheets, mounting plate, 2 mounting rails 18 x 39 mm, lock: 3 mm double bar |
| Width | 1.000 mm |
| Height | 2.000 mm |
| Depth | 400 mm |
| Mounting plate dimensions (W x H) | 899 mm x 1.896 mm |
| Degree of protection IP according to EN 60 529 | IP 55 |
| NEMA degree of protection | NEMA 1, NEMA 12 |
| Type rating according to UL 50E | Type 1, Type 12 |
| IK code | IK10 |
| Number of doors | 2 |
| Base material | steel sheet |
| PCF/VE (Cradle-to-Gate) | 413.95 kg CO2 eq (Cat B) |
| Note on PCF class | Category B: PCF value (Cradle-to-Gate) approximately calculated based on product weight and self-declared |
Questions & answers
What is the delivery time of Rittal 8004000 VX bayed enclosure system, 2-door, W x H x D: 1000x2000x400 mm, ?
The article Rittal 8004000 VX bayed enclosure system, 2-door, W x H x D: 1000x2000x400 mm, is currently in stock
According to our experience the article is ready for dispatch within 6 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Rittal 8004000 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Rittal 8004000 VX bayed enclosure system, 2-door, W x H x D: 1000x2000x400 mm, always at the best possible price. We can give you a discount of 2% on Rittal 8004000 VX bayed enclosure system, 2-door, W x H x D: 1000x2000x400 mm, if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
