Rittal 8609213 VX partition panel for module plates, height: 2000 mm, width: 600 mm

Your rating:
Average rating
product review for Rittal 8609213 VX partition panel for module plates, height: 2000 mm, width: 600 mm
( 4.5 / 5 ) 12 ratings
Rittal 8609213
This image may differ from the desired article.
Rittal 8609213Rittal 8609213Rittal 8609213
119,74 EUR
( 142,49 EUR incl. VAT )
≈ £100.22  |  ≈ $131.59
plus delivery charges: 148,00 €
Delivery time from supplier's stock (ca.) 12 workdaysinfo_outline
In Stock: >10 pieces
1x Rittal 8609213 VX partition panel for module plates, height: 2000 mm, width: 600 mm
Datasheet:file_download Download
Lieske Part No.:1440934
Mfg Part No: 8609213
UPC/EAN: 4028177817852
Weight:10.5 kg
Type:VX 8609.213

Product information for Rittal 8609213:

The Rittal VX 8609.213 is a partition panel for module plates, specifically designed for enclosures of type VX with a height of 2,000 mm and a depth of 600 mm. It serves for the structured division of the enclosure interior and enables the orderly mounting of module plates for connectors, cable entries, as well as the installation of busbar systems and other components. The partition panel is made of steel sheet with a thickness of 2.0 mm and features a zinc-coated surface, providing corrosion protection and increasing service life in industrial applications.

Applications
The partition panel is used in industrial electrical installations where a clear separation of switching and control components is required. It is particularly suitable for enclosures in which multiple modules or functional units need to be spatially separated to simplify maintenance and improve clarity. The symmetrical construction of the enclosure frame allows for mounting on the rear side of the enclosure, provided the dimensions permit.

Functions and Equipment in Detail
The partition panel features 10 cutouts, which can be used for mounting module plates, cable entries, or busbar systems. The continuous, double hemming provides additional stability and also serves as a mounting point for a gasket, ensuring a sealed and arc-resistant separation.

Technology Explained Simply
The use of steel sheet with a thickness of 2.0 mm ensures high mechanical strength, which is necessary for industrial environments. The zinc-coated surface protects the material against oxidative corrosion, especially in humid or aggressive environments. The double hemming along the edge of the partition panel increases stiffness and prevents deformation under load. The cutouts are precisely arranged to enable easy and secure mounting of module plates and other components.

Compatibility and Accessories
The partition panel is exclusively intended for enclosures of type VX with a height of 2,000 mm and a depth of 600 mm. For baying multiple enclosures in combination with a partition panel, additional components are required: either the baying bracket inside 8617500 or the baying connector outside 8617502. As suitable accessories, the VX cover hood with door, height: 2000x600 mm is also offered, enabling a lockable cover for the enclosure area.

Mounting and Installation
Mounting is carried out using the fastening materials included in the delivery. The partition panel can be mounted on the front or rear side of the enclosure, depending on the enclosure configuration, enabled by the symmetrical design of the frame. The cutouts are dimensioned to support the mounting of standard module plates and cable entries. When baying multiple enclosures, the use of the specified baying bracket or baying connector is necessary to ensure a stable connection.

Advantages in Operation
The partition panel improves clarity within the enclosure interior and simplifies maintenance and inspection of individual modules. The integrated cutouts reduce the need for additional drilling or cutting operations, shortening installation time. The robust construction from zinc-coated steel sheet ensures long service life and high reliability in industrial applications. The integrated gasket mounting supports a clean and arc-resistant separation, which is particularly important in environments with increased requirements for protection rating.

General
MaterialSheet steel, 2.0 mm
Surface protectionZinc-plated
Scope of deliveryIncluding mounting hardware
Suitable forEnclosure type: VX, height: = 2.000 mm, depth: = 600 mm
Number of breaks10
Mounting noteFor mounting in combination with a partition, the mounting bracket inside 8617500 or the mounting connector outside 8617502 is required


Product data sheet
Datasheet for Rittal 8609213, EAN: 4028177817852

Questions & answers

What is the delivery time of Rittal 8609213 VX partition panel for module plates, height: 2000 mm, width: 600 mm?

The article Rittal 8609213 VX partition panel for module plates, height: 2000 mm, width: 600 mm is currently in stock

According to our experience the article is ready for dispatch within 12 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Rittal 8609213 to our sales team for an exact delivery time.

How can I buy the item at a lower price?

We offer you Rittal 8609213 VX partition panel for module plates, height: 2000 mm, width: 600 mm always at the best possible price. We can give you a discount of 2% on Rittal 8609213 VX partition panel for module plates, height: 2000 mm, width: 600 mm if you choose payment in advance on ordering.

We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
