Rittal 8245000 VX bayed enclosure system, 2-door, W x H x D: 1200x1400x500 mm
|
787,75 EUR |
|
|
( 937,42 EUR incl. VAT ) ≈ £659.35 | ≈ $865.74 plus delivery charges |
|
| Delivery time from supplier's stock (ca.) 12 workdaysinfo_outline | |
| In Stock: >10 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 1440723 |
| Mfg Part No: | 8245000 |
| UPC/EAN: | 4028177813564 |
| Weight: | 141 kg |
| Type: | VX 8245.000 |
Product information for Rittal 8245000:
Applications
This enclosure system is designed for use in industrial environments where high mechanical load capacity and protection against dust and splashing water are required. It is suitable for use in production plants, automation systems, power supply installations, and other technical installations where secure and accessible mounting of electrical and electronic components is necessary. The construction allows for bayed mounting, enabling multiple enclosures to be arranged in a row to create larger systems.
Functions and Equipment in Detail
The enclosure system is supplied with a double-door front closure, with door hinges standardly mounted on the right, but toollessly switchable to the left. The doors are fitted with a PU foam seal to ensure a tight closure. The locking is achieved via a 3 mm double-barrel lock according to DIN 43668, enabling a four-point locking mechanism. The secondary door is additionally secured with a swing lever for double locking. The door opening is standardly 130° and can be toollessly extended to 180°. The clearance from the floor is 17 mm.
Technology Explained Simply
The protection rating IP 55 according to EN 60 529 ensures protection against dust and splashing water from any direction, making the enclosure system suitable for use in damp or dusty environments. The protection ratings NEMA 1 and NEMA 12, as well as the type rating according to UL 50E (Type 1 and Type 12), correspond to international standards for indoor use and protection against splashing water. The IK code IK10 means the enclosure is resistant to mechanical impacts up to 10 joules, indicating high mechanical strength. The mounting plate is adjustable in depth in 25 mm increments, allowing flexible adaptation to different components. Integrated plastic glides and reusable mounting rails facilitate positioning and securing of components.
Compatibility and Accessories
The enclosure system is compatible with various accessories that extend its use in different application scenarios. These include levelling feet M12 with an adjustment height of 18–43 mm, TS mounting rails for the external mounting plane, C-profile rails 30/15 according to EN 60715, VX partial mounting plates, cable routing spaces, transport eyes, VX base plates, comfort handles for various locking systems (e.g. half cylinder, ASSA, padlock), dust protection strips, cable entry ferrules in various diameters (e.g. 13 mm, 21 mm), multi-locking systems for padlocks, circuit diagram pockets in various depths (T600 mm, T90 mm), and an AS Multitool AX/VX. These accessories enable individual adaptation of the enclosure to specific mounting and protection requirements.
Mounting and Installation
Mounting is done via the integrated mounting planes, accessible from both inside and outside. The frame profiles are perforated in a 25 mm grid, enabling flexible fixation of components. The base plates are divided into three parts, removable and replaceable, allowing easy cleaning and maintenance. The rear panel and roof plate are removable and fitted with PU foam seals to ensure a tight closure. Electrical conductivity between frame, rear panel, roof, and base plates ensures automatic equipotential bonding according to DIN 62 208. Fixation to the floor is achieved via the welded base frame with integrated base reinforcement.
Advantages in Operation
The enclosure system offers high mechanical stability and load capacity up to 15,000 N. The double door construction with lockable closures ensures secure access and protection of installed components. The depth-adjustable mounting plate and integrated mounting planes enable flexible and space-saving installation. The use of sheet steel in various wall thicknesses ensures high strength and durability. The surface coating with textured lacquer in RAL 7035 provides good corrosion protection and visual harmony in industrial environments. The integrated seals and IP 55 protection rating protect internal components from environmental influences. The bayed construction allows modular expansion of installations, simplifying maintenance and system upgrades.
| General | |
| Material | Cabinet frame: steel sheet, 1.5 mm, roof: steel sheet, 1.5 mm, door: steel sheet, 2.0 mm, rear panel: steel sheet, 1.5 mm, base plates: steel sheet, 1.5 mm, mounting plate: steel sheet, 3.0 mm |
| Surface protection | Cabinet frame: dip-primed, door, roof and rear panel: dip-primed, externally powder-coated, textured lacquer, mounting plate and base sheets: galvanised |
| Colour | RAL 7035 |
| Scope of delivery | cabinet frame, door(s), door hinge right, reversible to left, roof sheet, rear panel, floor sheets, mounting plate, 2 mounting rails 18 x 39 mm, lock: 3 mm double bar |
| Width | 1.200 mm |
| Height | 1.400 mm |
| Depth | 500 mm |
| Mounting plate dimensions (W x H) | 1.099 mm x 1.296 mm |
| Degree of protection IP according to EN 60 529 | IP 55 |
| NEMA degree of protection | NEMA 1, NEMA 12 |
| Type rating according to UL 50E | Type 1, Type 12 |
| IK code | IK10 |
| Number of doors | 2 |
| Base material | steel sheet |
| PCF/VE (Cradle-to-Gate) | 367.57 kg CO2 eq (Cat B) |
| Note on PCF class | Category B: PCF value (Cradle-to-Gate) approximately calculated based on product weight and self-declared |
Questions & answers
What is the delivery time of Rittal 8245000 VX bayed enclosure system, 2-door, W x H x D: 1200x1400x500 mm?
The article Rittal 8245000 VX bayed enclosure system, 2-door, W x H x D: 1200x1400x500 mm is currently in stock
According to our experience the article is ready for dispatch within 12 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Rittal 8245000 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Rittal 8245000 VX bayed enclosure system, 2-door, W x H x D: 1200x1400x500 mm always at the best possible price. We can give you a discount of 2% on Rittal 8245000 VX bayed enclosure system, 2-door, W x H x D: 1200x1400x500 mm if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
