Rittal 1566000 terminal box KX, stainless steel 1.4301, without mounting plate
|
198,49 EUR 206,43 EUR |
|
|
( 236,20 EUR incl. VAT ) ≈ £166.14 | ≈ $218.14 plus delivery charges: 55,00 € |
|
| Delivery time from supplier's stock (ca.) 6 workdaysinfo_outline | |
| In Stock: >100 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 1778292 |
| Mfg Part No: | 1566000 |
| UPC/EAN: | 4028177919204 |
| Weight: | 2.866 kg |
| Type: | KX 1566000 |
Product information for Rittal 1566000:
Applications
This terminal box is designed for use in industrial environments, particularly in areas with high humidity, dust exposure, or aggressive chemicals. The protection rating IP 66 according to EN 60 529 ensures dust-tight and water-tight sealing, even under strong splashing water, making it suitable for outdoor use or in damp indoor areas. The approvals according to NEMA (NEMA 1, 3R, 3RX, 4, 4X, 12) and UL 50E (Type 1, 3R, 3RX, 4, 4X, 12) confirm suitability for various industrial requirements, including mounting in damp, dusty, or mildly corrosive environments.
Functions and Equipment in Detail
The housing is made as a single piece, bent and welded, creating a stable, wear-resistant construction. The rear wall is closed and features embossing for secure mounting. The lid is equipped with a continuous protective flange that additionally protects the seal. Earthing is achieved via a protective conductor connection in the housing and a bolt in the lid, ensuring quick and secure earthing. The delivery includes the housing with lid and four quick-release fasteners including plastic bushings, enabling simple and secure locking.
Technology Explained Simply
The material thickness of 1.25 mm for housing and lid ensures sufficient strength to withstand mechanical loads. The use of stainless steel 1.4301 (AISI 304) provides high corrosion resistance, especially against moisture and mild chemicals. The IP protection rating 66 means the housing is dust-tight and protected against strong splashing water, which is crucial for use in damp or wet environments. The PU seal ensures a tight seal between housing and lid, maintaining the protective function over the long term.
Compatibility and Accessories
Various accessories are available for this terminal box, expanding mounting and usage options. These include mounting clips for support rails, support rails in formats TH 35/7.5 and TS 35/15, mounting brackets, stainless steel 1.4404 lid hinges, condensate drains, baying sets for combination with other KX models, ST 4.8 L9.5 mm screws, mounting brackets, wall mounting brackets made of stainless steel 1.4301, SZ pressure equalization plugs made of stainless steel 1.4305, AX mast mounting brackets, earthing straps M6-M6 with a cross-section of 10 mm², mounting plates for terminal boxes and bus enclosures, mounting claws for a second mounting level, and SZ wall mounting brackets made of stainless steel 1.4301. These components enable flexible and application-specific mounting, e.g., on walls, support rails, or masts.
Mounting and Installation
Mounting is done via the designated fastening points on the housing. The quick-release fasteners allow for easy and quick lid installation. When using accessories such as wall mounting brackets or support rails, the terminal box can be mounted on various substrates. Mounting plates and mounting claws allow use on multiple mounting levels, which is advantageous for complex installations.
Operational Advantages
The terminal box offers high mechanical stability and corrosion resistance, increasing service life and reliability in demanding environments. The IP 66 protection rating ensures reliable protection against dust and water, guaranteeing operational safety. The integrated earthing via protective conductor connection and bolt in the lid simplifies secure electrical connection. The brush-finished surface is easy to clean and provides a uniform visual appearance. The use of stainless steel 1.4301 (AISI 304) ensures high resistance to environmental influences, especially in damp or mildly corrosive environments. The accessory compatibility allows flexible adaptation to different mounting conditions and requirements.
| General | |
| Material | Housing: Stainless steel 1.4301 (AISI 304), Cover: Stainless steel 1.4301 (AISI 304), continuous foamed PU seal |
| Surface protection | Housing and cover: fine grinding, grit 180 |
| Scope of delivery | Housing with cover, quick-release fastener including plastic inserts |
| Width | 300 mm |
| Height | 200 mm |
| Depth | 120 mm |
| Degree of protection IP according to EN 60 529 | IP 66 |
| NEMA degree of protection | NEMA 1, NEMA 3R, NEMA 3RX, NEMA 4, NEMA 4X, NEMA 12 |
| Type rating according to UL 50E | Type 1, Type 3R, Type 3RX, Type 4, Type 4X, Type 12 |
| Material thickness cover | 1,25 mm |
| Plate thickness cabinet | 1,25 mm |
| Lock | Number of locks: 4 |
| Base material | Stainless steel 1.4301 (AISI 304) |
| PCF/VE (Cradle-to-Gate) | 11,33 |
