ATEN EA1240 Temperature & Humidity Sensor 2m content_copy

For environmental monitoring and management, ATEN provides sensor probes that work in tandem with the Power Distribution Units, which enable you to get readings of temperate and humidity. Environmental conditions can be monitored with alarms according to customizable minimum/maximum thresholds set for temperature and humidity.
*The Sensor is an optional accessory. You can use the ATEN PDU without environmental sensors. However, if you want to have complete energy management of your data center with the full use of ATEN solutions, a sensor installation is required.Measurement range: – °C (Temperature); 30 – 80 % RH (Humidity)
Measurement accuracy: +/- 1°C (Temperature); +/- 3 % RH (Humidity)
Compact design – built in 3m cable
High sensitivity
Package Contents1x EA1240 Temperature & Humidity sensor
1x Sensor mount
4x Tie wrap
3x Adhesive cable tie holder
ConnectorsRJ-11 Male
Measurement
RangeTemperature: 0 - 40°C
Humidity: 30– 80% RH
AccuracyTemperature: +/- 1°C
Humidity: +/- 3 % RH
Supply Voltage5 VDC (Max)
Current Consumption5mA(Max); 2mA(Avg.)
Environmental
Operating Temperature0 - 55°C
Storage Temperature-20 - 70°C
Humidity
Physical Properties
HousingPlastic
Weight0.06 kg
Cable Length3 m

Features
Sensor type	Temperature & humidity sensor
Connectivity technology	Wired
Standard interfaces	RJ-11
Temperature measuring range	0 - 40 °C
Humidity measuring range	30 - 80%
Accuracy	1 °C
Cable length	3 m
Material	Plastic
Logistics data
Master (outer) case net weight	1.6 kg
Master (outer) case width	420 mm
Master (outer) case length	230 mm
Master (outer) case height	190 mm
Master (outer) case gross weight	2.75 kg
Products per master (outer) case	20 pc(s)
Operational conditions
Operating temperature (T-T)	0 - 55 °C
Storage temperature (T-T)	-20 - 70 °C
Operating relative humidity (H-H)	0 - 95%
Packaging data
Package width	110 mm
Package depth	160 mm
Package height	40 mm
Package weight	120 g
Technical data
Height packaging	0.040m
Weight	0.120kg
Width packaging	0.110m
Packaging volume	0.0007m³
Length packaging	0.200m
Weight & dimensions
Weight	80 g

---
