ATEN CS1708A KVM Switch VGA PS/2-USB USB Peripherals Port 8 Ports
|
-14% 333,59 EUR 389,99 EUR |
|
|
( 396,97 EUR incl. VAT ) ≈ £283.22 | ≈ $375.96 plus delivery charges: 53,00 € |
|
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |
| Lieske Part No.: | 807679 |
|---|---|
| Mfg Part No: | CS1708A |
| UPC/EAN: | 4710423775312 |
| Weight: | 3.78 kg |
Product information for Aten CS1708A:
Device Type: KVM-/USB-Switch - 8 ports - stackable Enclosure Type: Desktop, rack-mountable - 1U Ports: 8 x KVM / USB, no. KVM Local Users Qty: 1 local user, keyboard-/mouse: PS / 2, USB, Max Units In A Stack: 31, Max Resolution: 2048 x 1536, Features: Firmware upgradable, video DynaSync, Status Indicators: Link activity, power, choice, Interfaces: Keyboard / video / mouse (KVM): 8 x D-Sub (DB-15 ), 15-pin | Network stack device: 1 x input - D-Sub (DB-25), 25-pin | Network stack device: 1 x output - D-Sub (DB-25), 25-pin | Keyboard / mouse / video / USB: 1 x 18 pin SPHD | 1 x RJ-11 - management | USB: 1 x USB Type A, 4-pole, Power Device: Power adapter - external, Power Consumption Operational: 5 Watts, Width: 16 cm, depth: 43.3 cm, height: 4.4 mm, weight: 2.7 kg, Cables Included: 2 x keyboard / mouse / video cable | 1 x Console Cable, Mounting Kit: Included, Rack Mounting Kit: Included, Compliant Standards: DDC-2B , RoHS, WEEE, Min Operating Temperature: 0 ° C Max Operating temperature: 50 ° C Humidity Range Operating: 0 - 80% (non-condensing), Min Storage temperature: -20 ° C Max Storage temperature: 60 ° C
| Design | |
| Rack capacity | 1U |
| Product colour | Black |
| Housing material | Metal |
| Rack mounting | |
| LED indicators | |
| Push button | |
| Hot keys | |
| Display | |
| Built-in display | |
| On Screen Display (OSD) | |
| Logistics data | |
| Master (outer) case net weight | 10.2 kg |
| Harmonized System (HS) code | 85176200 |
| Master (outer) case width | 375 mm |
| Master (outer) case length | 565 mm |
| Master (outer) case height | 258 mm |
| Master (outer) case gross weight | 12.2 kg |
| Products per master (outer) case | 3 pc(s) |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Packaging content | |
| Cables included | KVM |
| Packaging data | |
| Package width | 116 mm |
| Package depth | 540 mm |
| Package height | 233 mm |
| Package weight | 3.85 kg |
| Performance | |
| HD type | QXGA |
| Maximum resolution | 2048 x 1536 pixels |
| Scan interval | 1,255 s |
| DDC/DDC2 supported | |
| DDC2B support | |
| Daisy chain | |
| Firmware upgradeable | |
| Ports & interfaces | |
| Number of computers controlled | 256 |
| Keyboard port type | USB, PS/2 |
| Mouse port type | USB, PS/2 |
| Video port type | VGA |
| Console ports | USB A, VGA (D-Sub) |
| Console USB ports quantity | 1 |
| USB connector type | USB Type-A |
| DC-in jack | |
| Power | |
| Power source | DC |
| Input voltage | 5.3 V |
| Power consumption (typical) | 5 W |
| Sustainability | |
| Compliance certificates | RoHS |
| System requirements | |
| Windows operating systems supported | |
| Linux operating systems supported | |
| Mac operating systems supported | |
| Weight & dimensions | |
| Width | 437.2 mm |
| Depth | 159.9 mm |
| Height | 44 mm |
| Weight | 3.41 kg |
Questions & answers
What is the delivery time of ATEN CS1708A KVM Switch VGA PS/2-USB USB Peripherals Port 8 Ports?
The article ATEN CS1708A KVM Switch VGA PS/2-USB USB Peripherals Port 8 Ports is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Aten CS1708A to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you ATEN CS1708A KVM Switch VGA PS/2-USB USB Peripherals Port 8 Ports always at the best possible price. We can give you a discount of 2% on ATEN CS1708A KVM Switch VGA PS/2-USB USB Peripherals Port 8 Ports if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
