Softing IT Networks 228206 Softing WireXpert MP, zbh. Singlemode-Messkabel Kit SC-LC/APC, 2 m Duplex, Referenzqualität content_copy

The Singlemode test cable kit SC-LC/APC, 2m Duplex from Softing IT Networks is a reference quality set for precise measurement and analysis of singlemode fibre cables in the field of network technology. It serves as standard accessory for fibre measurement devices and enables the performance of loss measurements, reflection measurements and other optical tests on fibre installations. The kit is specifically designed for use with measurement devices such as the WireXpert MP to ensure reproducible and reliable measurement results.

Applications
This test cable set is used in the professional field of IT infrastructure and telecommunications, particularly for commissioning, maintenance and troubleshooting in singlemode fibre installations. The cables are designed for use in duplex systems, enabling simultaneous data transmission in both directions. The use of APC connectors (Angled Physical Contact) ensures minimal reflections at connection points, which is especially important for high-speed applications and long transmission distances.

Functions and equipment in detail
The kit contains a total of six test cables and four couplers. This includes two duplex test cables with LC/APC-LC/APC connectors, each having a length of 2 metres. These cables serve as reference cables for calibration and measurement. Additionally, four single cables of type SC-LC/APC are included, serving as connection cables between the measurement device and the cable system to be tested. The LC/APC couplers enable secure and clean connection of the cables to each other or to other fibre components.

Technology explained simply
The LC and SC connectors used are standard connectors in fibre optic communication. LC connectors are compact and commonly used in modern network devices, while SC connectors offer a robust, easy-to-handle design. The APC designation stands for Angled Physical Contact, meaning the fibre end faces are polished at an angle of 8°. This reduces back reflections at the connection point, which is crucial for signal quality in singlemode systems. The cables are designed for singlemode fibres, i.e. for light transmission in a single mode, enabling high bandwidths and long transmission distances.

Compatibility and accessories
The kit is specifically designed for use with fibre measurement devices such as the WireXpert MP from Softing IT Networks. The cables and couplers are dimensioned to meet the requirements of reference cables necessary for precise measurements. The use of APC connectors ensures compatibility with other APC systems in the network. The cables are designed for duplex applications, meaning they integrate two fibres in one cable to enable bidirectional data transmission.

Installation and mounting
Installation is performed by simply plugging the cables into the corresponding connectors of the measurement device and the fibre installation to be tested. The couplers serve as connection elements between the cables and allow flexible adaptation of the measurement configuration. The cables are designed with a length of 2 metres to ensure sufficient reach for typical measurement tasks without being unnecessarily long. Handling requires no special tools, as the connectors are mechanically locked.

Advantages in operation
The use of this reference cable set ensures high measurement accuracy and reproducibility of results. The APC connectors minimise back reflections, improving signal quality and reducing measurement errors. The combination of LC and SC connectors enables flexible adaptation to different devices and installations. The duplex configuration of the cables supports efficient performance of measurements in bidirectional systems.
