Rittal 5501635 component shelf pull-out 2 U 48,3 cm ( 19 inch ) 25 kg 350 mm RAL9005
|
118,92 EUR |
|
|
( 141,51 EUR incl. VAT ) ≈ £99.54 | ≈ $130.69 plus delivery charges: 55,00 € |
|
| Delivery time from supplier's stock (ca.) 12 workdaysinfo_outline | |
| In Stock: >100 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 1130319 |
| Mfg Part No: | 5501635 |
| UPC/EAN: | 4028177679078 |
| Weight: | 3.74 kg |
| Type: | DK 5501635 |
Product information for Rittal 5501635:
Component shelf
The component shelf is designed as a 2 U module, making it suitable for mounting standard IT and electrical devices in 48,3 cm ( 19 inch ) format. It is delivered pre-assembled, simplifying installation. The pre-assembled version includes telescopic rails for the pull-out function and a grip recess for safe and convenient access.
Functions and equipment in detail
The component shelf enables full pull-out, providing complete access to devices inside the enclosure. The rails are self-locking, meaning the base remains securely locked in the fully extended position and does not unintentionally slide back. Tool-free installation significantly simplifies the setup, as no screwdrivers or other tools are required. Mounting is achieved via pre-installed flanges, which are directly attached to the mounting plane inside the enclosure.
Technology explained clearly
The telescopic rails ensure smooth, friction-free movement of the component shelf. The self-locking feature is achieved through integrated locking pins, which automatically engage in the locked position when pulled out. The material choice of sheet steel ensures high mechanical stability and durability, even under load. The RAL 9005 paint finish provides a corrosion-resistant surface suitable for industrial and technical environments.
Compatibility and accessories
The component shelf is designed for enclosures with a 48,3 cm ( 19 inch ) mounting plane (482.6 mm) and can be used in wall- or floor-mounted enclosures. It is specifically designed for use in Rittal enclosures but is also compatible with other manufacturers, provided the mounting plane meets the 48,3 cm ( 19 inch ) standard. The pre-assembled version with mounting hardware reduces installation time and minimizes installation errors.
Mounting and installation
Mounting is tool-free. The pre-installed flanges are attached to the mounting plane inside the enclosure, with the telescopic rails already correctly positioned. The grip recess allows for a secure grip, and the locking pins ensure secure locking in the extended position. Installation is quick and requires no additional mounting aids.
Advantages in operation
The component shelf provides simple, safe, and reliable access to installed devices. The tool-free design and full pull-out function increase efficiency during maintenance and service work. The static load capacity of 250 N ensures that even heavier devices can be securely mounted. The robust construction from sheet steel and the painted surface in RAL 9005 ensure long service life and a professional appearance in technical installations.
| General | |
| Material | steel sheet |
| Surface protection | Painted |
| Colour | RAL 9005 |
| Scope of delivery | Device base, pre-assembled, including fastening material |
| Static load capacity | 250 N |
| Contact surface | Width: 430 mm, Depth: 300 mm |
Questions & answers
What is the delivery time of Rittal 5501635 component shelf pull-out 2 U 48,3 cm ( 19 inch ) 25 kg 350 mm RAL9005?
The article Rittal 5501635 component shelf pull-out 2 U 48,3 cm ( 19 inch ) 25 kg 350 mm RAL9005 is currently in stock
According to our experience the article is ready for dispatch within 12 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Rittal 5501635 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Rittal 5501635 component shelf pull-out 2 U 48,3 cm ( 19 inch ) 25 kg 350 mm RAL9005 always at the best possible price. We can give you a discount of 2% on Rittal 5501635 component shelf pull-out 2 U 48,3 cm ( 19 inch ) 25 kg 350 mm RAL9005 if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
