Rittal 7507030 FlatBox DK 15 U W x D 600x400 mm grey 48,3 cm ( 19 inch ) mounting frame

Your rating:
Average rating
product review for Rittal 7507030 FlatBox DK 15 U W x D 600x400 mm grey 48,3 cm ( 19 inch ) mounting frame
( 4.5 / 5 ) 122 ratings
Rittal 7507030
This image may differ from the desired article.
Rittal 7507030Rittal 7507030Rittal 7507030Rittal 7507030Rittal 7507030Rittal 7507030Rittal 7507030
-9% 377,55 EUR 414,40 EUR
( 449,28 EUR incl. VAT )
≈ £316.01  |  ≈ $414.93
plus delivery charges: 235,00 €
Delivery time from supplier's stock (ca.) 9 workdaysinfo_outline
In Stock: >50 pieces
1x Rittal 7507030 FlatBox DK 15 U W x D 600x400 mm grey 48,3 cm ( 19 inch ) mounting frame
Datasheet:file_download Download
Lieske Part No.:746697
Mfg Part No: 7507030
UPC/EAN: 4028177551428
Weight:29 kg
Type:DK 7507030

Product information for Rittal 7507030:

For flexible use as a wall-mounted or floor-standing enclosure.
Benefits: Tool-free quick assembly
System assembly on the open 482.6 mm (48,3 cm ( 19 inch )) frame
Material: Sheet steel
Viewing window: Single-pane safety glass, 3 mm
Surface finish: Powder-coated
Colour: RAL 7035
Supply includes: Flat-packed enclosure
1 wall section
2 basic supports
2 roof/base plates, with cut-outs for cable entry via brush strips
2 side panels, lockable
1 glazed door, lockable, security lock 3524 E, door hinge point selectable
Connection components for tool-free, fast assembly
Earthing kit for system-compatible earthing of all enclosure parts
1 pc(s). 482.6 mm (48,3 cm ( 19 inch )) mounting frame
4 pc(s). Levelling feet
Note: Max. installation depth: Depth - 58 mm to rear panel
Max. distance between two 482.6 mm (48,3 cm ( 19 inch )) levels: Depth - 104 mm
Packs of: 1 pc(s).
EAN: 4028177551428
Customs tariff number: 94032080
eCl@ss 5.1: 27180204
eCl@ss 7.0: 27180208
ETIM 6.0: EC002500

Design: with 482.6 mm (48,3 cm ( 19 inch )) mounting frame
Dimensions: Width: 600 mm
Height: 758 mm
Depth: 400 mm
Installation height for components: 15 U
Weight/pack: 30.1 kg

General
Modelwith 19" mounting frame
MaterialSheet steel, viewing window: single-pane safety glass, 3 mm
Surface protectionPowder-coated
ColourRAL 7035
Scope of deliveryEnclosure in flat-pack packaging, 1 wall section, 2 base carriers, 2 roof/base sheets, with cutouts for cable entry via brush strips, 4 brush strips, 2 side walls, lockable, 1 vision door, lockable, safety lock 3524 E, door hinge freely selectable, connection elements for tool-free quick assembly, grounding kit for system-compliant grounding of all enclosure parts, 19" mounting frame
Height units15 HE
Width600 mm
Height758 mm
Depth400 mm
Component mounting height15 HE
Load capacitymax. 750 N
NoteMax. installation depth: depth - 58 mm to rear wall, max. spacing between two 19" shelves: depth - 104 mm, maximum door opening angle is 210°
Base materialsteel sheet
PCF/VE (Cradle-to-Gate)114.3 kg CO2 eq (Cat B)
Note on PCF classCategory B: PCF value (Cradle-to-Gate) approximately calculated based on product weight and self-declared


Please note...
This article has over-weight and though needs to be transported by a forwarding agency. Please mind, that the calculation of the delivery charges in the shopping cart disregard this aspect. Though, there will be corresponding surcharges after you send us your order.
Product data sheet
Datasheet for Rittal 7507030, EAN: 4028177551428

Questions & answers

What is the delivery time of Rittal 7507030 FlatBox DK 15 U W x D 600x400 mm grey 48,3 cm ( 19 inch ) mounting frame?

The article Rittal 7507030 FlatBox DK 15 U W x D 600x400 mm grey 48,3 cm ( 19 inch ) mounting frame is currently in stock

According to our experience the article is ready for dispatch within 9 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Rittal 7507030 to our sales team for an exact delivery time.

How can I buy the item at a lower price?

We offer you Rittal 7507030 FlatBox DK 15 U W x D 600x400 mm grey 48,3 cm ( 19 inch ) mounting frame always at the best possible price. We can give you a discount of 2% on Rittal 7507030 FlatBox DK 15 U W x D 600x400 mm grey 48,3 cm ( 19 inch ) mounting frame if you choose payment in advance on ordering.

We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
