Rittal 2500212 System light LED 900, 100-240 V, L: 437 mm, with plug

Your rating:
Average rating
product review for Rittal 2500212 System light LED 900, 100-240 V, L: 437 mm, with plug
( 4.5 / 5 ) 6 ratings
Rittal 2500212
This image may differ from the desired article.
Rittal 2500212Rittal 2500212Rittal 2500212Rittal 2500212Rittal 2500212
119,95 EUR
( 142,74 EUR incl. VAT )
≈ £100.40  |  ≈ $131.83
plus delivery charges: 55,00 €
Delivery time from supplier's stock (ca.) 12 workdaysinfo_outline
In Stock: >50 pieces
1x Rittal 2500212 System light LED 900, 100-240 V, L: 437 mm, with plug
Datasheet:file_download Download
Lieske Part No.:1599183
Mfg Part No: 2500212
UPC/EAN: 4028177811348
Weight:0.622 kg
Type:SZ 2500212

Product information for Rittal 2500212:

Rittal SZ 2500212 is an LED system light, specifically designed for use in enclosures. It provides uniform and sufficient illumination of the entire enclosure interior, enabling safe and efficient maintenance and operation. The light features an integrated socket in F/B format (Type E, CEE 7/5), suitable for powering devices within the enclosure, particularly in countries such as Belgium and France. The housing is finished in RAL 7016, providing a neutral, grey-black tone that blends well in industrial environments.

Applications

The light is intended for use in industrial enclosures where reliable and uniform illumination is required. It is particularly suitable for installations requiring frequent access to electrical components, such as in automation technology, manufacturing industry, or power supply. The integrated socket also allows for the direct power supply of auxiliary devices, such as measuring instruments or fans, directly within the enclosure.

Functions and Equipment in Detail

The SZ 2500212 delivers a luminous flux of 900 lumens at a colour temperature of 4000 K (neutral white), ensuring clear and natural perception of the enclosure equipment. The rated power is 11 W, ensuring energy-efficient lighting. The light is equipped with a 90° rotatable socket, allowing flexible positioning of the socket. Installation is carried out directly on the enclosure profile with a 25 mm mounting grid, with fastening possible via screwing or clip mounting. The required mounting screws are included in the delivery scope.

Technology Explained Simply

The light operates using LED technology, offering long service life and low heat generation. The rated insulation voltage is 300 V AC, and the rated impulse voltage withstand (phase to earth) is 2500 V AC, ensuring electrical safety. Protection class II (double insulated) means the light can be operated without an additional protective earth conductor. Protection rating IP 20 protects against contact with fingers and against solid foreign objects, but not against water or dust. The operating temperature range extends from -20 °C to +55 °C, enabling use in a wide range of environments.

Compatibility and Accessories

The light is equipped with various connection options: supply (3-pole), pass-through wiring (3-pole), and connection to a door position switch. These functions enable flexible integration into existing enclosure systems. These components allow individual adaptation of wiring and mounting.

Mounting and Installation

Mounting is performed directly on the enclosure profile with a 25 mm mounting grid, with the light either screwed or clipped in place. Mounting screws are included in the delivery scope. The connection options allow flexible wiring, with supply and pass-through wiring via 3-pole connections. A door position switch can be used to automatically activate the lighting when the enclosure door is opened.

Operational Advantages

The SZ 2500212 provides bright, uniform illumination of the entire enclosure interior, enhancing workplace safety. The integrated socket enables direct power supply of devices within the enclosure, eliminating the need for external sockets or additional wiring. LED technology ensures long service life and low maintenance costs. Mounting is simple and quick, thanks to the provided fastening options on the enclosure profile. Protection rating IP 20 and an operating temperature range of -20 °C to +55 °C make the light suitable for a wide range of industrial applications.

General
ModelWith socket
MaterialLuminaire body: extruded aluminium, luminaire cover: polycarbonate, luminaire ends: PC-ABS
ColourHousing: RAL 7016
Scope of deliveryIncluding mounting screws
Nominal power11 W
Connection optionsPower supply, 3-pole, through wiring, 3-pole, door position switch
Overvoltage protection classII
Protection classII (double insulated)
Luminaires mounting typeScrewing, clip mounting
Rated impulse voltage withstand, phase to ground2500 V AC
Rated insulation voltage300 V AC
Mounting optionsDirect mounting on cabinet profile with 25 mm grid
Luminous flux900 lm
Colour of light4000 K (neutral white)
NoteConnection accessories to be ordered separately
Width437 mm
Height80 mm
Depth44 mm
Operating temperature range-20 °C...55 °C
Socket outletsF/B (Type E, CEE 7/5)
Rated operating voltage100 V - 230 V, 1~, 50 Hz/60 Hz
Socket configurationF/B (Type E, CEE 7/5)
Degree of protection IP according to IEC 60 529IP 20
PCF/VE (Cradle-to-Gate)13,6


Product data sheet
Datasheet for Rittal 2500212, EAN: 4028177811348
