Rittal 7501000 VerticalBox DK 5 U spacing 434–489 mm grey
|
251,26 EUR 251,36 EUR |
|
|
( 299,00 EUR incl. VAT ) ≈ £212.31 | ≈ $281.16 plus delivery charges: 148,00 € |
|
| Delivery time from supplier's stock (ca.) 7 workdaysinfo_outline | |
| In Stock: >10 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 104380 |
| Mfg Part No: | 7501000 |
| UPC/EAN: | 4028177625426 |
| Weight: | 17.04 kg |
| Type: | DK 7501000 |
Further Wallmount Racks from RittalFurther products in category Wallmount Racks
All products of Rittal
Product information for Rittal 7501000:
Compact 482.6 mm (48,3 cm ( 19 inch )) enclosure for small networks.
Benefits: May be used as wall-mounted, under-desk or desktop enclosure
Free access from three sides for interior installation
Passive ventilation with vent slots
Rear panel prepared to accommodate a fan
Freely selectable door hinging
Material: Sheet steel
Viewing window: Single-pane safety glass, 3 mm
Surface finish: Powder-coated
Colour: RAL 7035
Supply includes: Enclosure with glazed door
Side panels (1 x fixed, 1 x slot-in) with vent slots
Knockouts for cable entry via roof or base
Slot-in rear panel with knockouts for cable entry and fan accommodation
482.6 mm (48,3 cm ( 19 inch )) mounting level, 5 U, horizontal front and rear, depth-variable, distance between levels 434 – 489 mm
Security lock 12321 on the door, side and rear panel
4 plastic feet, self-adhesive
Packs of: 1 pc(s).
EAN: 4028177625426
Customs tariff number: 94032080
eCl@ss 5.1: 27180204
eCl@ss 7.0: 27180208
ETIM 6.0: EC002500
Dimensions: Width: 300 mm
Height: 540 mm
Depth: 600 mm
Installation height for components: 5 U
Weight/pack: 17.3 kg
Benefits: May be used as wall-mounted, under-desk or desktop enclosure
Free access from three sides for interior installation
Passive ventilation with vent slots
Rear panel prepared to accommodate a fan
Freely selectable door hinging
Material: Sheet steel
Viewing window: Single-pane safety glass, 3 mm
Surface finish: Powder-coated
Colour: RAL 7035
Supply includes: Enclosure with glazed door
Side panels (1 x fixed, 1 x slot-in) with vent slots
Knockouts for cable entry via roof or base
Slot-in rear panel with knockouts for cable entry and fan accommodation
482.6 mm (48,3 cm ( 19 inch )) mounting level, 5 U, horizontal front and rear, depth-variable, distance between levels 434 – 489 mm
Security lock 12321 on the door, side and rear panel
4 plastic feet, self-adhesive
Packs of: 1 pc(s).
EAN: 4028177625426
Customs tariff number: 94032080
eCl@ss 5.1: 27180204
eCl@ss 7.0: 27180208
ETIM 6.0: EC002500
Dimensions: Width: 300 mm
Height: 540 mm
Depth: 600 mm
Installation height for components: 5 U
Weight/pack: 17.3 kg
Please note...
This article has over-weight and though needs to be transported by a forwarding agency. Please mind, that the calculation of the delivery charges in the shopping cart disregard this aspect.
Though, there will be corresponding surcharges after you send us your order.
