ALLNET Switch unmanaged Layer2 5 Port? 5x 2.5GbE? PoE budget 55W? 5x PoE at ? Fanless? ALL-SG8005P-2.5G

ALLNET Switch unmanaged 5 port 2.5GBit / 5x PoE / 1x LAN | Fanless / ALL-SG8005P-2.5G" Highlights: Five multi-gigabit ports support up to 2.5 gigabit 4x speed (10M/100M/1G/2.5G). 5x ports Multi-PoE compatible with IEEE802.3af or IEEE802.3at Increase network speed by 2.5 times without additional cabling costs. Plug and play, no complicated installation. The fanless design ensures completely silent operation. Flexible mounting options for placing the 2.5G switch in your environment ON/OFF button on the front Supports IEEE802.1x flow control Supports Jumbo Frame: 12K bytes Backwards compatible to 10Mbit/100Mbit and 1Gbit The 2.5 Gigabit switch ALL-SG8005P- 2.5G is the perfect candidate if you want to expand the speed and performance of your network. It is up to 2.5 times faster than today's gigabit networks. As an out-of-the-box network speed upgrade, the ALL-SG8005P-2.5G is an optimal solution for home or small office users who need more bandwidth for their network, e.g. for online gaming, multimedia streaming services or faster wireless network connections without the need for complex configuration.Mechanical Details: Technical Details: Items Specifications Model No. ALL-SG8005P-2.5G Key Components Realtek RTL8371+RTL8221Bx5
IC+ IP804AR PoE PSE Controller I/O ports 5 x 2.5Gigabit Ethernet ports, RJ45 PoE ports Port# 1~ 4
IEEE802.3at, IEEE802.3af LED Define Power: Green LEDOff : power off or fail On: power on Blinking: system booting up PoE Alert: Green LED Off: No over PoE max power budget (50W) On: Over PoE max power budget (50W) RJ 45 Port: LINK/ACT: bio- color LEDOff: port disconnected or link fail Green on: 2.5Mbps connected Amber on: 10/100/1000Mbps connected Blinking: sending or receiving data PoE:Off: PoE power output off Green on: PoE power output on HW feature IEEE802.3u 100BASE -TX IEEE802.3ab 1000BASE-T IEEE802.3bz 2.5G BASE-T IEEE802.3az EEE
IEEE802.1x Flow control MAC address Table: 16K Packet buffer size: 12Mbit Jumbo Frame: 12K bytes
Forwarding Rate: 18.6pps (64-byte) PoE power pin-out Alternative A (Pin 1.2/3.6) PoE power budget Alert: 50W
Budget: 55W PoE Output power capacity Maximum output :30W per each portCompliant with IEEE802.3af/at standard, Following IEEE802.3at/at to support PoE or PoE+ Automatically discover the connection of PD device and immediately sends power to it Auto disable port if the port current is over 700mA or short happens Priority default setting is lower port NO. has high priority The maximum power used by power devices is defined by the following classification. When Port works in Auto Mode, the output port power limit will be associated with PD classification Value. Follow the standard PSE pin-out standard of Alternative A (MAD-X) which is sending out power over number 1,2,3,6 pins of 8 wires of Ethernet CAT5 UTP cable Power Input AC-to-DC external power adapter Input : 100-240V AC
Output: 55V DC/1.3A Dimension 160 x 110 x 26 mm FAN Design Fanless Temperature Operating: 0 ~ 40°C
Storage : -40 ~ 70°C Humidity Operating: 10% ~ 90% RH (non- condensing)
Storage: 5% ~ 90% RH (non-condensing)
