Allnet ALL-RJ45-Magnet TP-TP coupling, CAT6A, socket, 1:1, 8-pin, RJ45, safety coupling, push-out socket, PoE-capable, up to 10 GBit (ABS housing) - -V2 content_copy

The RJ45 safety coupling from Allnet, type ALL-RJ45-Magnet, is a release socket providing protection function for IT devices in network infrastructures. It consists of two magnetically connected parts that disengage under excessive pulling force, preventing the ripping out of RJ45 sockets and associated damage to devices. The coupling was specifically developed for use in the hospitality sector and IT system houses, where high mechanical stress can occur due to carelessness or accidental pulling on cables. The release force of the coupling is below the standard requirements for RJ45 connectors according to IEC 60603-7, ensuring the connection always breaks before mechanical damage to the device occurs. Unintentional disengagement of the magnetic connection is not possible, as the magnetic fixation remains stable as long as no critical pulling force is applied.

Applications

The safety coupling is suitable for all applications where network cables are connected to sensitive devices, such as switches, routers, PoE end devices, or servers. It is particularly suitable in environments with high personnel traffic, such as hotels, restaurants, conference rooms, or industrial environments, where cables may be accidentally pulled or overloaded. The coupling allows the use of existing network infrastructures, as it is compatible with all common RJ45 plugs from Cat5 to Cat6a.

Functions and Features in Detail

The coupling consists of a plug and a socket part connected via magnetic contacts. The connection disengages when the preset pulling force is exceeded, thereby protecting the device. The magnetic connection is stable and prevents accidental disengagement. The socket complies with the connector standard IEC 60603-7-51 and is thus suitable for use in standardized networks. The coupling supports Power over Ethernet (PoE) according to IEEE 802.3 af/at/bt, with a maximum power transmission of 90 watts. This enables the power supply of PoE-capable devices such as IP cameras, access points, or telephones via the network cable.

Technology Explained Simply

The coupling operates with neodymium Pogo pins, arranged in a 2x4-pole connection. These pins ensure a reliable electrical connection and enable bidirectional, full-duplex data transmission. The maximum data transfer rate is up to 10 GBit/s according to IEEE 802.3an, allowing use in modern high-speed networks. The coupling is manufactured in an ABS housing, which is robust and resistant to mechanical stress. The housing color is white, enabling unobtrusive integration into existing installations. The operating temperature ranges from -20°C to 85°C, and humidity can range from 10% to 90%, ensuring broad usability in various environments.

Compatibility and Accessories

The coupling is compatible with all RJ45 plugs of categories Cat5 to Cat6a. It supports PoE technologies according to IEEE 802.3 af/at/bt and thus enables power supply of end devices via the network cable. The coupling is designed as an inactive adapter, meaning it transmits signals without modification. The delivery includes a 2-piece release plug set in ABS housing, a patch cable RJ45 CAT6 with 250 MHz bandwidth, 0.15 m length, white, UTP (U/UTP), Synergy 21, as well as a function test report created using a Cable-Eye measuring device.

Installation and Mounting

Installation is done by simply inserting the plug into the socket. The magnetic connection ensures secure fixation, which only disengages under excessive pulling force. The coupling can be installed at any RJ45 socket or device equipped with an RJ45 port. Mounting requires no tools and is therefore quick and easy to perform.

Operational Advantages

The safety coupling provides reliable protection against mechanical damage to IT devices. The magnetic connection ensures a stable connection that only disengages under critical pulling force. Compatibility with PoE and high data rates makes the coupling suitable for modern networks. The robust construction from ABS plastic and broad temperature and humidity resistance enable use in various environments. The coupling complies with EU Directive 2002/95/EC (RoHS) and is therefore environmentally compatible.

General
Maximum PoE power	90 Watt
RoHS compliant

---
