TP-LINK TL-SF1024D 24 Ports Ethernet Switch - 10/100Base-T - 24 x Network - Twisted Pair content_copy

What This Product Does

The 24-Port 10/100Mbps Switch TL-SF1024D provides you with a high-performance, low-cost, easy-to-use, seamless and standard upgrade to improve old network to 100Mbps network. All 24 ports support auto MDI/MDIX, no need to worry about the cable type, simply plug and play. Moreover, with the innovative energy-efficient technology, the TL-SF1024D can save up to 75% of the power consumption and 80% of the packaging material can be recycled, making it an eco-friendly solution for your business network. TP-LINK Green Technology This new generation The 24-Port 10/100Mbps Switch TL-SF1024D features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status and cable length to limit the carbon footprint of your network. It also complies with the EU'S RoHS, prohibiting the use of certain hazardous materials. Besides, 80% of the packaging material can be recycled. High Performance The rack-mount size steel case design, combined with a safety-certified internal power supply, make the switch the most robust product, which is very cost-effective for a less than 16-user environment. Featuring non-blocking switching architecture, TL-SF1024D forwards and filters packets at full wire-speed for maximum throughput. And IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode alleviate the traffic congestion and make TL-SF1024D work reliably. Easy to Use The auto features of this fast ethernet switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminates the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (10, 100 Mbps) and intelligently adjusts for compatibility and optimal performance.

Certificates
Certification	FCC, CE, RoHS
Data transmission
Switching capacity	10 Gbit/s
Throughput	3.57 Mpps
MAC address table	8000 entries
Packet buffer memory	2 MB
Design
Product colour	Black
Rack mounting
LED indicators
Management features
Quality of Service (QoS) support
Network
Networking standards	IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
10G support
Auto MDI/MDI-X
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 90%
Performance
Compatible operating systems	Microsoft Windows 8, 7,Vista, XP MAC OS NetWare UNIX Linux
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Power connector	DC-in jack
Power
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	3.53 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Weight & dimensions
Width	294 mm
Depth	180 mm
Height	44 mm

---
