Rittal 8618000 VX viewing door, W x H: 600x1800 mm

Your rating:
Average rating
product review for Rittal 8618000 VX viewing door, W x H: 600x1800 mm
( 4.5 / 5 ) 12 ratings
Rittal 8618000
This image may differ from the desired article.
Rittal 8618000Rittal 8618000Rittal 8618000
396,41 EUR 396,61 EUR
( 471,73 EUR incl. VAT )
≈ £331.80  |  ≈ $435.65
plus delivery charges: 148,00 €
Delivery time from supplier's stock (ca.) 8 workdaysinfo_outline
In Stock: >10 pieces
1x Rittal 8618000 VX viewing door, W x H: 600x1800 mm
Datasheet:file_download Download
Lieske Part No.:1440916
Mfg Part No: 8618000
UPC/EAN: 4028177921085
Weight:13 kg
Type:VX 8618.000

Product information for Rittal 8618000:

The Rittal VX 8618.000 is a viewing door for enclosures of type VX, designed as a replacement for a steel sheet door or rear panel. It enables visual inspection of the enclosure's interior without opening the door, thereby improving operational monitoring and maintenance efficiency. The door is designed for enclosures with a width of 600 mm and a height of 1,800 mm, fitting standard VX enclosures of these dimensions.

Applications

The viewing door is used in industrial plants, automation technology, and electrical engineering, where continuous visibility of installed components such as switching devices, wiring, or controls is required. It is particularly suitable for systems where quick visual checks of operating conditions, such as LEDs or indicators, are necessary without opening the door. When used instead of a rear panel, special lock inserts designed for frame 8618.110 are required.

Functions and Equipment in Detail

The door consists of a frame made of aluminium extruded profile, providing high mechanical stability. The viewing pane is made of single-pane safety glass with a thickness of 3 mm, ensuring clear visibility and high safety. The frame surface is powder-coated, providing high corrosion resistance and uniform colour. The frame colour corresponds to RAL 7035, while the inner printed mask on the viewing pane is in RAL 9005, enabling a high-contrast, easily readable view of the interior.

Technology Explained Simply

The door is equipped with a rod lock system operating with a double-barrel lock insert to ensure secure and reliable locking. Installation is carried out using four 180° hinges, allowing full door opening and ensuring unobstructed access to the enclosure interior. The protection rating IP 55 according to IEC 60 529 protects against dust and splashing water, making the door suitable for industrial environments with increased contamination or moisture exposure. The IK code IK08 provides protection against mechanical impacts such as shocks or blows with an energy of up to 5.3 J, highlighting the robust construction. Certification according to UL 50E as Type 1 and Type 12 confirms suitability for indoor use with limited dust and splashing water exposure.

Compatibility and Accessories

The viewing door is specifically designed for VX enclosures with dimensions of 600 mm width and 1,800 mm height. As an accessory, the VX lock insert is available, which is required when installing the door in place of a rear panel to ensure secure locking. The use of lock inserts for frame 8618.110 is explicitly mentioned in the manufacturer's specifications.

Installation and Mounting

The door is mounted in place of a steel sheet door or rear panel. The hinges allow a 180° opening, enabling the door to be fully swung aside. The viewing pane is securely integrated into the frame, and locking is achieved via the rod lock with double-barrel insert. When mounted in place of a rear panel, the use of special lock inserts for frame 8618.110 is required to ensure mechanical safety.

Operational Advantages

The viewing door enables continuous visual monitoring of the enclosure interior without opening the door. This reduces the risk of operational disruptions and enhances safety, as no enclosure opening is required. The high mechanical stability and protection ratings IP 55 and IK08 ensure reliable performance in demanding industrial environments. The powder-coated surface ensures long service life and resistance to corrosion and contamination.

General
MaterialFrame: aluminium extruded profile, viewing panel: single-pane safety glass, 3 mm
Surface protectionPowder-coated
ColourFrame: RAL 7035, viewing window (internally printed mask): RAL 9005
Scope of deliveryVision door, bar lock with double-bar insert, 180° hinges (4 pieces)
IK codeIK08
NoteWhen mounted instead of rear panel, locking parts for frame 8618.110 are required
Type rating according to UL 50EType 1, Type 12
Degree of protection IP according to IEC 60 529IP 55
Suitable forCabinet type: VX, width: = 600 mm, height: = 1,800 mm


Product data sheet
Datasheet for Rittal 8618000, EAN: 4028177921085

Questions & answers

What is the delivery time of Rittal 8618000 VX viewing door, W x H: 600x1800 mm?

The article Rittal 8618000 VX viewing door, W x H: 600x1800 mm is currently in stock

According to our experience the article is ready for dispatch within 8 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Rittal 8618000 to our sales team for an exact delivery time.

How can I buy the item at a lower price?

We offer you Rittal 8618000 VX viewing door, W x H: 600x1800 mm always at the best possible price. We can give you a discount of 2% on Rittal 8618000 VX viewing door, W x H: 600x1800 mm if you choose payment in advance on ordering.

We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
