Rittal 7979139 PDU basic 32A/3P CEE 12xC13+12xC19 (freight shipping)

Your rating:
Average rating
product review for Rittal 7979139 PDU basic 32A/3P CEE 12xC13+12xC19 (freight shipping)
( 4 / 5 ) 1 ratings
Rittal 7979139
This image may differ from the desired article.
Rittal 7979139Rittal 7979139Rittal 7979139Rittal 7979139Rittal 7979139Rittal 7979139Rittal 7979139Rittal 7979139
-10% 410,55 EUR 454,10 EUR
( 488,55 EUR incl. VAT )
≈ £343.63  |  ≈ $451.19
plus delivery charges: 100,00 €
Delivery time from supplier's stock (ca.) 12 workdaysinfo_outline
In Stock: 1 pieces
1x Rittal 7979139 PDU basic 32A/3P CEE 12xC13+12xC19 (freight shipping)
Datasheet:file_download Download
Lieske Part No.:1910545
Mfg Part No: 7979139
UPC/EAN: 4028177947559
Weight:5.4 kg
Type:DK 7979139

Product information for Rittal 7979139:

The Rittal DK 7979139 is a PDU Basic power distribution unit, specifically designed for use in IT server and network enclosures. It serves as a compact basic power distribution solution and enables professional electrical power supply for IT systems. The device is manufactured from a robust aluminium extrusion profile, anodized, with socket outlets made of plastic. The overall dimensions are 44 mm width, 1,495 mm length, and 70 mm depth, ensuring efficient space utilization in standard 48,3 cm ( 19 inch ) racks. The power distribution unit is designed for a rated operating voltage of 400 V (AC) and supports a nominal current of up to 32 A, corresponding to a nominal power of 22 kW. Power input is via a CEE connection type with a 3 m long supply cable, enabling flexible installation in IT infrastructures.

Applications include use in IT server and network enclosures, particularly in racks of the Rittal VX IT type. The PDU is suitable for vertical mounting in Zero-U-Space, where tool-free installation is possible when using the Rittal VX IT or TS IT rack. Horizontal mounting in the 48,3 cm ( 19 inch ) plane is also possible, depending on requirements. The power distribution unit is designed for enclosure types with a minimum length of 1,800 mm, whether mounted on the enclosure frame or on the 48,3 cm ( 19 inch ) profile rails.

Functions and equipment in detail include 12 socket outlets of type IEC 60320/C13 and 12 socket outlets of type IEC 60320/C19. The socket outlets are color-coded to distinguish phases and fuse circuits: L1 is pink, L2 is black, and L3 is white. This facilitates assignment and maintenance, especially in multi-phase installations. The delivery includes a socket lock for IEC C14 and C20 plugs, protecting against accidental disconnection of plugs. Additionally, mounting hardware is included, enabling tool-free installation in the Rittal VX IT or TS IT rack. Unused socket outlets can be sealed with accessories available separately, preventing unintentional overloading of individual phases or circuits.

Technology explained simply shows that the PDU basic features a fixed supply cable with a CEE plug, directly connected to the power supply. The power distribution unit is designed for operation in a temperature range of 5 °C to 50 °C, with humidity up to 95 % (non-condensing). Storage temperature ranges from -20 °C to 70 °C. Compliance with the EMC Directive 2014/30/EU and the Low Voltage Directive 2014/35/EU ensures electromagnetic compatibility and safety in low-voltage installations. Standards EN 62368-1, EN 61000-3, EN 61000-4, EN 61000-6, and EN 62053-21 guarantee conformity with international standards for safety, EMC, and measurement accuracy.

Compatibility and accessories include use with Rittal VX IT and TS IT racks. Accessories available include monitoring systems CMC III with CAN-bus cables in various lengths (0.5 m, 1.0 m, 1.5 m), covers for C13 and C19 sockets, mounting adapters for TE 8000, universal locks, numeric code lock for CMC III, VX IT CMC III transponder reader (RAL 9005), and surge protection modules Type 3 with replaceable discharge elements during operation. These modules can be integrated into the PDU enclosure and provide additional protection against surges. Surge protection status monitoring is performed via a potential-free alarm contact.

Mounting and installation are tool-free in the Rittal VX IT or TS IT rack, with the included universal holder and mounting hardware enabling quick and secure installation. Vertical mounting in Zero-U-Space is possible, minimizing rack space requirements. Horizontal mounting in the 48,3 cm ( 19 inch ) plane is also provided, depending on infrastructure requirements.

Operational advantages include easy installation, high reliability due to robust materials, and clear color-coding of phases. The integrated socket lock and the option to cover unused socket outlets increase safety and prevent overloads. Compatibility with intelligent monitoring systems such as CMC III enables extended operational monitoring and fault diagnosis. The PDU basic is thus a reliable and flexible solution for power distribution in IT infrastructures.

General
ModelPDU Basic
MaterialAluminium extruded profile, anodized, socket positions: plastic
Scope of deliveryPlug lock for IEC C14, C20 plugs, including mounting hardware
OptionsSurge protection Type 3 with replaceable discharge devices during operation, with status monitoring, integrable in PDU enclosure, other enclosure colours available
Width44 mm
Depth70 mm
Length1.495 mm
Number of sockets and type12 x C13 / 12 x C19
Rated operating voltage400 V (AC)
Rated current (max.)32 A
Nominal power22 kW
Power suppliesNumber: 1, phases per input: 3~
Connection cable length3 m
Electrical connection typeCEE
PoliciesEMC Directive 2014/30/EU, Low Voltage Directive 2014/35/EU
StandardsEN 62368-1, EN 61000-3, EN 61000-4, EN 61000-6, EN 62053-21
Operating temperature range5 °C...50 °C
Humidity (non-condensing)10...95 %
Storage temperature range-20 °C...70 °C
Suitable forHousing type: VX IT cabinet frame: ≥ 1,800 mm, housing type: VX IT 19"-profile rails: ≥ 1,800 mm


Product data sheet
Datasheet for Rittal 7979139, EAN: 4028177947559
