Rittal 7979134 PDU basic 32A/3P CEE 24xCEE7/3 Schuko

Your rating:
Average rating
product review for Rittal 7979134 PDU basic 32A/3P CEE 24xCEE7/3 Schuko
( 4.4 / 5 ) 5 ratings
Rittal 7979134
This image may differ from the desired article.
Rittal 7979134Rittal 7979134Rittal 7979134Rittal 7979134Rittal 7979134Rittal 7979134Rittal 7979134Rittal 7979134
296,01 EUR 298,20 EUR
( 352,25 EUR incl. VAT )
≈ £247.76  |  ≈ $325.31
plus delivery charges: 100,00 €
Made to order · Delivery time approx. 5 workdaysinfo_outline
1x Rittal 7979134 PDU basic 32A/3P CEE 24xCEE7/3 Schuko
Datasheet:file_download Download
Lieske Part No.:1775591
Mfg Part No: 7979134
UPC/EAN: 4028177947504
Weight:6.3 kg
Type:DK 7979134

Product information for Rittal 7979134:

The Rittal DK 7979134 is a PDU Basic power distribution unit, specifically designed for use in IT server and network enclosures. It serves as a compact base power distribution unit, professionally supplying electrical power to IT racks. The unit features 24 sockets of type Schuko (CEE 7/3), rated for an operating voltage of 400 V (AC). The maximum rated current is 32 A, corresponding to a rated power of 22 kW. Power supply is via a single input with three phases (3~), with the supply cable having a length of 3 m and equipped with a CEE plug. The PDU is designed for use in racks of type VX IT, with mounting possible on enclosure frames with a minimum length of 1,800 mm or on 48,3 cm ( 19 inch ) profile rails from 2,000 mm.

Applications
The PDU basic is suitable for use in professional IT environments, particularly in server and network enclosures, where reliable and structured power supply is required. It is designed for indoor operation and can be mounted either horizontally in the 48,3 cm ( 19 inch ) plane or vertically. A particular advantage is the possibility of mounting in Zero-U-Space, preserving valuable rack space. Tool-free mounting in Rittal VX IT or TS IT racks is achieved using a supplied universal holder, enabling quick and secure installation.

Functions and Equipment in Detail
The power distribution unit features a robust housing made of aluminum extrusion profile, anodized, providing high mechanical stability and corrosion resistance. The socket outlets are made of plastic and are securely mounted. The phases (L1, L2, L3) are color-coded (L1=pink, L2=black, L3=white) to ensure clear identification and safe wiring. The delivery includes socket locks for IEC C14 and C20 plugs as well as the mounting hardware for installation. The locks protect the plug connections against accidental disconnection. Unused sockets can be sealed with optional covers available as accessories, preventing unintentional overloading of individual phases or circuits.

Technology Explained Simply
The PDU basic is designed for an operating temperature range of 5 °C to 50 °C and can be used in environments with air humidity from 10 % to 95 % (non-condensing). Storage is possible at temperatures from -20 °C to 70 °C. The unit complies with relevant European directives, including the EMC Directive 2014/30/EU and the Low Voltage Directive 2014/35/EU. Additionally, it meets the standards EN 62368-1, EN 61000-3, EN 61000-4, EN 61000-6, and EN 62053-21, ensuring safety, electromagnetic compatibility, and measurement accuracy. Power supply is via the CEE supply cable, which connects directly to the input. The PDU is immediately operational once mounted and connected.

Compatibility and Accessories
The PDU basic is specifically designed for use in Rittal VX IT enclosures, with mounting possible on enclosure frames from 1,800 mm or on 48,3 cm ( 19 inch ) profile rails from 2,000 mm. Various accessory options are available, including Type 3 surge protection with replaceable discharge modules during operation, which can be integrated into the PDU housing. Additionally, covers for C13 and C19 sockets, mounting adapters, CAN-Bus cables for the CMC III monitoring system, as well as numeric code locks and transponder readers are available. These components enable extended functionality, such as status monitoring or protection against unauthorized access.

Mounting and Installation
Mounting is tool-free in Rittal VX IT or TS IT racks using the supplied universal holder. Vertical mounting in Zero-U-Space is possible, optimizing rack space utilization. Fixing is done using the supplied mounting materials, ensuring secure and stable anchoring. The unit is designed for installation without additional tools or aids.

Operational Advantages
The PDU basic provides reliable and structured power supply for IT systems. The color-coding of phases and socket locking enhance safety and prevent incorrect connections. The Zero-U-Space mounting option optimizes space requirements in the rack. Integrated compatibility with accessories such as surge protection modules and monitoring systems allows for flexible functional expansion. Compliance with relevant standards and directives ensures safe and reliable operation in professional environments.

General
ModelPDU Basic
MaterialAluminium extruded profile, anodized, socket positions: plastic
Scope of deliveryPlug lock for IEC C14, C20 plugs, including mounting hardware
OptionsSurge protection Type 3 with replaceable discharge devices during operation, with status monitoring, integrable in PDU enclosure, other enclosure colours available
Width44 mm
Depth70 mm
Length1.695 mm
Number of sockets and type24 x Schuko (Type F, CEE 7/3)
Rated operating voltage400 V (AC)
Rated current (max.)32 A
Nominal power22 kW
Power suppliesNumber: 1, phases per input: 3~
Connection cable length3 m
Electrical connection typeCEE
PoliciesEMC Directive 2014/30/EU, Low Voltage Directive 2014/35/EU
StandardsEN 62368-1, EN 61000-3, EN 61000-4, EN 61000-6, EN 62053-21
Operating temperature range5 °C...50 °C
Humidity (non-condensing)10...95 %
Storage temperature range-20 °C...70 °C
Suitable forHousing type: VX IT cabinet frame: ≥ 1,800 mm, housing type: VX IT 19"-profile rails: ≥ 2,000 mm


Product data sheet
Datasheet for Rittal 7979134, EAN: 4028177947504
