Rittal 6539010 command panel housing, stainless steel 1.4301, 600x400x150 mm
|
460,00 EUR 478,40 EUR |
|
|
( 547,40 EUR incl. VAT ) ≈ £388.70 | ≈ $514.28 plus delivery charges: 148,00 € |
|
| Delivery time from supplier's stock (ca.) 7 workdaysinfo_outline | |
| In Stock: >5 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 653472 |
| Mfg Part No: | 6539010 |
| UPC/EAN: | 4028177220393 |
| Weight: | 12.15 kg |
| Type: | CP 6539010 |
Further System Accessories from RittalFurther products in category System Accessories
All products of Rittal
Product information for Rittal 6539010:
Material: Enclosure and door: Stainless steel 1.4301 (AISI 304)
Handle strips: Plastic approved for use with foodstuffs, dyed blue
Surface finish: Brushed, grain 240
Colour: Handle strips: similar to RAL 5002
Protection category IP to IEC 60 529: IP 66
Protection category NEMA: NEMA 12
Supply includes: Enclosure of all-round solid construction
Cut-out and reinforcement for support arm system CP 40 stainless steel
Fastener with guide plate
Door with sealing frame and side handle strips
Lock: 3 mm double-bit
Note: The support arm connection and door hinge may be swapped over by rotating the enclosure
Matching mounting plates from compact enclosures AE may be used
3 mm double-bit lock insert may be exchanged for 41 mm lock inserts, plastic handles and T handles, type C
Note on Model No.: Matching mounting panel 5050.436
Packs of: 1 pc(s).
EAN: 4028177220393
Customs tariff number: 94032080
eCl@ss 5.1: 27180505
eCl@ss 7.0: 27180505
ETIM 6.0: EC002504
Dimensions: Width: 600 mm
Height: 400 mm
Depth: 150 mm
Weight/pack: 12.1 kg
Handle strips: Plastic approved for use with foodstuffs, dyed blue
Surface finish: Brushed, grain 240
Colour: Handle strips: similar to RAL 5002
Protection category IP to IEC 60 529: IP 66
Protection category NEMA: NEMA 12
Supply includes: Enclosure of all-round solid construction
Cut-out and reinforcement for support arm system CP 40 stainless steel
Fastener with guide plate
Door with sealing frame and side handle strips
Lock: 3 mm double-bit
Note: The support arm connection and door hinge may be swapped over by rotating the enclosure
Matching mounting plates from compact enclosures AE may be used
3 mm double-bit lock insert may be exchanged for 41 mm lock inserts, plastic handles and T handles, type C
Note on Model No.: Matching mounting panel 5050.436
Packs of: 1 pc(s).
EAN: 4028177220393
Customs tariff number: 94032080
eCl@ss 5.1: 27180505
eCl@ss 7.0: 27180505
ETIM 6.0: EC002504
Dimensions: Width: 600 mm
Height: 400 mm
Depth: 150 mm
Weight/pack: 12.1 kg
Questions & answers
What is the delivery time of Rittal 6539010 command panel housing, stainless steel 1.4301, 600x400x150 mm?
The article Rittal 6539010 command panel housing, stainless steel 1.4301, 600x400x150 mm is currently in stock
According to our experience the article is ready for dispatch within 7 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Rittal 6539010 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Rittal 6539010 command panel housing, stainless steel 1.4301, 600x400x150 mm always at the best possible price. We can give you a discount of 2% on Rittal 6539010 command panel housing, stainless steel 1.4301, 600x400x150 mm if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
