Microsens MS100210DX ind. GBIC SFP 1000Mbps, single mode / LC

The Small Form Factor Pluggable (SFP) transceiver module is a versatile and replaceable component of the new generation designed for modern network infrastructures. With its compact form factor, it allows for maximum port density per line card, offering maximum flexibility for use in networking devices with 1G interfaces. Thanks to its hot-swap functionality, the modules can be installed or replaced during operation without disrupting the network.

The energy-efficient Low Power SFPs (LPC SFP) deliver the same transmission performance as standard modules while consuming only 70% of the electrical energy. This not only reduces power consumption but also minimizes heat generation, supporting an efficient and sustainable network infrastructure. Compliance with MSA and SFF-8472 standards ensures standardized design and support for digital diagnostic functions (DDM), providing enhanced monitoring and management capabilities.

Technical Specifications:

Transceiver Types:

• MS100200DX-V2
• MS100210DX-V2
• MS100221DXA-V2
• MS100221DXB-V2

Connector:

• LC plug (duplex or simplex, depending on the model)

Supported Cable Media:

• Multimode
• Singlemode
• Singlemode simplex

Range:

• 300 m to 20 km (depending on the model)

Power Consumption:

• Maximum 0.6 W

Operating Temperature:

• -40 °C to +85 °C

Bandwidth:

• 1.063 Gbps to 1.25 Gbps

Wavelength Range:

• TX: 830–1570 nm (depending on the model)
• RX: 830–1330 nm (depending on the model)

Power Budget:

• 7.5 dB to 15 dB (depending on the model)

Laser Type:

• VCSEL (850 nm)
• FP Laser (1310 nm)
• DFB Laser (1550 nm)

Protocol Support:

• Gigabit Ethernet
• Gigabit Fibre Channel

Transmit (Power):

• MIN/MAX: -9.5 / -3 dBm

Receiver (Sensitivity):

• MIN/MAX (overload): -17 / -3 dBm to -24 / -3 dBm (depending on the model)

Extinction Ratio:

• 6 dB

Features:

• Hot-swappable
• Energy-efficient Low-Power models
• Digital diagnostic interface (DDM)
• Compliant with MSA and SFF-8472 standards
• Laser Class 1 safety certification

Safety Notes:

Never look directly into optical ports, as visible and invisible laser light can cause eye damage.

Always cover unused ports with protective caps.

Ensure all connections are completed before activating the transmission line.

Ordering Information:

MS100200DX-V2: LPC SFP GbE Transceiver 1.25G SX, Multimode, 850nm, DDM, LC, -40..+85°C

MS100210DX-V2: LPC SFP GbE Transceiver 1.25G LX, SingleMode, 1310nm, 10km, DDM, LC, -40..+85°C

MS100221DXA-V2: LPC SFP GbE WDM Transceiver 1.25G BX, SingleMode TX1310nm / RX1550nm, 20km, DDM, LC simplex, -40..+85°C

MS100221DXB-V2: LPC SFP GbE WDM Transceiver 1.25G BX, SingleMode TX1550nm / RX1310nm, 20km, DDM, LC simplex, -40..+85°C
