Eaton 101446 DILM32-XTEY20 RA24 time module 24 V AC/DC 1–30 s star-delta
|
108,01 EUR 112,55 EUR |
|||||||||||
|
( 128,53 EUR incl. VAT ) ≈ £90.40 | ≈ $118.70 plus delivery charges: 55,00 € |
|||||||||||
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |||||||||||
| Lieske Part No.: | 1242874 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 101446 | ||||||||||
| UPC/EAN: | 4015081013661 | ||||||||||
| Weight: | 0.123 kg | ||||||||||
| Type: | DILM32-XTEY20(RA24) | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Eaton 101446:
Applications
This time module is used in installations where motors with high starting power are operated, such as in pump, fan, or conveyor systems. The star-delta configuration enables a smooth start, reducing mechanical stress on the drive. Typical applications include industrial manufacturing, process engineering, and building automation, where controlled motor control is required.
Functions and Features in Detail
The time module offers an adjustable time range for switching time from 1 to 30 seconds, with a switching pause of 50 milliseconds. These settings allow application-specific adjustment of the start duration to match specific operating conditions. The integrated protective circuits ensure safe shutdown in case of faults and prevent unwanted switching operations. The mounting position is arbitrary, but not in a hanging orientation, to ensure correct function of the internal mechanics.
Technology Explained Simply
The time module operates with an electronic timing control powered by a 24 V AC/DC supply voltage. The timing control enables precise and reproducible switching between star and delta configurations. The protective circuits are designed to block switching in case of faults or disturbances, thus preventing damage to the installation. The protection rating IP20 safeguards against entry of solid foreign objects larger than 12.5 mm and protects against contact with moving parts, but does not protect against water or dust.
Compatibility and Accessories
The time module is specifically developed for use with Eaton contactors from the mentioned series. It is not combinable with auxiliary switches, which restricts mounting and use to specific control panels. Compatible contactors that can be used with this time module include models such as DILM7, DILM12, DILM15, DILM25, DILM32, and DILM38, as well as the series DILMP, DILA, and DILMF. The mentioned models are available in various power ratings and voltage settings, with compatibility limited to specific types.
Mounting and Installation
Mounting is done directly onto the corresponding Eaton contactors, with an arbitrary mounting position, but not in a hanging orientation. Connection is made via integrated terminal clamps designed for 24 V AC/DC voltage. Installation requires no additional tools or components, as the time module is designed as a modular accessory. The integrated protective circuits are pre-configured and require no additional programming or adjustment.
Advantages in Operation
Using this time module enables reliable and precise control of star-delta control applications. The adjustable switching time from 1 to 30 seconds provides flexibility in adapting to different drive requirements. The integrated protective circuits increase safety and extend the service life of the installation. Compatibility with a wide range of Eaton contactors simplifies integration into existing control panels and reduces the need for additional control elements. The protection rating IP20 ensures safe operation in indoor environments under normal operating conditions.
| General | |
| Degree of protection | IP20 |
| Operating voltage | 24 V AC/DC |
| Switching time | 1 - 30 s |
| Switching pause | 50 ms |
| Built-in position | any, except hanging |
| Compatibility | DILM7 - DILM38, DILMP20, DILMP32-DILMP45, DILA, DILMF7, DILMF11, DILMF14, DILMF25, DILMF32 |
| Standards and regulations | DIN EN 61812, IEC/EN 60947, VDE 0660, UL, CSA |
Questions & answers
What is the delivery time of Eaton 101446 DILM32-XTEY20 RA24 time module 24 V AC/DC 1–30 s star-delta ?
The article Eaton 101446 DILM32-XTEY20 RA24 time module 24 V AC/DC 1–30 s star-delta is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Eaton 101446 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Eaton 101446 DILM32-XTEY20 RA24 time module 24 V AC/DC 1–30 s star-delta always at the best possible price. We can give you a discount of 2% on Eaton 101446 DILM32-XTEY20 RA24 time module 24 V AC/DC 1–30 s star-delta if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduated prizes with every purchase. If you buy a minimum of 5 pieces of Eaton 101446 DILM32-XTEY20 RA24 time module 24 V AC/DC 1–30 s star-delta we can offer you a price of 103,96 EUR per piece. The more you buy, the cheaper the article will be.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
