ATEN VS0801H 8-Port HDMI A/V Switch with Infrared Remote Control content_copy

With more and more HDMI devices entering the Home Theater market, the need for simultaneous access to different HDMI A/V sources is becoming increasingly important. Now, the VS0801H 8-port HDMI Switch offers an easy and affordable way to add HDMI capabilities to your home theater system by allowing you to switch easily between up to eight HDMI A/V sources (such as an HD camcorder or satellite box, HD-DVD player, hi-def Blu-ray player, home theater PC, stand-alone streaming media player, gaming console, etc. ) that are connected to your HDMI display.The remote control and convenient front panel push buttons allow you to quickly and easily toggle between HDMI sources, while the front panel LEDs indicate the source device at a glance. Furthermore, for complete system and install integration, RS-232 control is standard through the VS0801H's built-in bi-directional RS-232 serial remote port that allows the switch to be controlled through a high-end controller, PC, or home automation/home theater software package.

Features
Material	Metal
Product colour	Black, Silver
Maximum refresh rate	60 Hz
Maximum operating distance	15 m
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Supported video modes	480p, 720p, 1080i, 1080p
Bandwidth	6.75 Gbit/s
Maximum resolution	1920 x 1200 pixels
HD type	Full HD
Dolby technologies	DTS-HD Master Audio, Dolby TrueHD
Input impedance	100 Ω
Output impedance	100 Ω
HDCP version	1.4
Consumer Electronics Control (CEC) support
Plug and Play
HDCP
Rack mounting
LED indicators
3D
Logistics data
Harmonized System (HS) code	85176990
Master (outer) case width	375 mm
Master (outer) case length	565 mm
Master (outer) case height	258 mm
Master (outer) case gross weight	8.14 kg
Products per master (outer) case	3 pc(s)
Master (outer) case net weight	6 kg
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 80%
Storage relative humidity (H-H)	0 - 80%
Packaging content
Quantity per pack	1 pc(s)
Mounting kit
Remote control included
User guide
AC adapter included
Packaging data
Package width	116 mm
Package depth	540 mm
Package height	233 mm
Package weight	2.48 kg
Ports & interfaces
Video port type	HDMI
HDMI ports quantity	9
HDMI in	8
Number of HDMI outputs	1
RS-232 ports	1
DC-in jack
Power
Power consumption (typical)	3.73 W
Weight & dimensions
Width	159.8 mm
Depth	437 mm
Height	44 mm
Weight	2 kg

---
