Aten KVM switch 8-way VGA/USB/TP, LAN (IP-capable), 1xlocal/2xLAN/4x additional remote (modem, network)
|
-22% 1.547,62 EUR 1.985,38 EUR |
|
|
( 1.841,67 EUR incl. VAT ) ≈ £1,303.10 | ≈ $1,737.98 plus delivery charges: 83,00 € |
|
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 1375997 |
| Mfg Part No: | KN1108VA |
| UPC/EAN: | 4719264645303 |
| Weight: | 5.475 kg |
Product information for Aten KN1108VA:
*Order-related, cannot be canceled*, (keyboard, mouse), 1U, 48,3 cm ( 19 inch ), mouse/keyboard simulation, resolution 1920 x 1200, console: 1xVGA HDB-15 socket, 2xPS/2 sockets, 2x USB sockets, PC 1-8: each (1xRJ-45 socket) LAN IP: 2xRJ-45 socket, Remote: 4x RJ-45 socket -Laptop USB Console (LUC) An independent USB port for directly connecting a laptop for easy console operation -High video resolutions up to 1920 x 1200* at 60 Hz for local and remote sessions -Panel Array Mode available for local console operators and remote users -High quality security supports FIPS 140-2 Level 1 security standards
| Design | |
| Rack capacity | 1U |
| Product colour | Black |
| Housing material | Metal |
| Rack mounting | |
| Wired remote switch | |
| Cascadable | |
| LED indicators | |
| Push button | |
| Hot keys | |
| Display | |
| Built-in display | |
| Logistics data | |
| Master (outer) case net weight | 4.37 kg |
| Harmonized System (HS) code | 85176200 |
| Master (outer) case width | 338 mm |
| Master (outer) case length | 515 mm |
| Master (outer) case height | 155 mm |
| Master (outer) case gross weight | 5.58 kg |
| Products per master (outer) case | 1 pc(s) |
| Network | |
| Ethernet LAN (RJ-45) ports | 14 |
| Cabling technology | 10/100/1000Base-T(X) |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Security algorithms | 802.1x RADIUS, FIPS 140-2, RSA, SSL/TLS |
| Ethernet LAN | |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Packaging content | |
| Cables included | AC |
| Manual | |
| Rack mount kit | |
| Packaging data | |
| Package width | 338 mm |
| Package depth | 515 mm |
| Package height | 155 mm |
| Package weight | 5.58 kg |
| Performance | |
| Maximum resolution | 1920 x 1200 pixels |
| Scan interval | 1,255 s |
| Number of users | 64 user(s) |
| Firmware upgradeable | |
| Ports & interfaces | |
| Number of computers controlled | 8 |
| Keyboard port type | USB, PS/2 |
| Mouse port type | USB, PS/2 |
| Video port type | VGA |
| Console ports | USB A, Mini-DIN |
| Console USB ports quantity | 2 |
| USB 2.0 Type-A hub ports quantity | 3 |
| USB connector type | Mini-USB B, USB Type-A |
| PS/2 ports quantity | 2 |
| Serial port type | RJ-45 |
| Serial ports quantity | 2 |
| Headphone outputs | 1 |
| Number of microphone inputs | 1 |
| USB hub | |
| Audio connections | |
| Power | |
| Power source | AC |
| Input voltage | 100 - 240 V |
| AC input frequency | 50 / 60 Hz |
| Input current | 1 A |
| Sustainability | |
| Compliance certificates | RoHS |
| System requirements | |
| Windows operating systems supported | |
| Linux operating systems supported | |
| Mac operating systems supported | |
| Weight & dimensions | |
| Width | 438.4 mm |
| Depth | 287.8 mm |
| Height | 44 mm |
| Weight | 4.37 kg |
