Allied Telesis AT-IMC2000TP/SC-980 ALLIED TAA 10/100/1000T POE+ to 1000SX/SC Industrial Temp Gigabit Media Converter
|
321,08 EUR |
|
|
( 382,09 EUR incl. VAT ) ≈ £272.28 | ≈ $359.93 plus delivery charges: 53,00 € |
|
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |
| Lieske Part No.: | 1116610 |
|---|---|
| Mfg Part No: | AT-IMC2000TP/SC-980 |
| UPC/EAN: | 0767035210551 |
| Weight: | 0.57 kg |
| Type: | PERP |
Product information for Allied Telesis AT-IMC2000TP/SC-980:
| Certificates | |
| Compliance certificates | RoHS |
| Safety | UL 62368-1, EN 62368-1, UL 60950-1 (UL), CAN/CSA C22.2 No. 60950-1 (cUL), EN 60950-1 (TUV) |
| Certification | TAA FCC A, EN55024, EN55032, EN55035, VCCI A |
| Features | |
| Product colour | Grey |
| International Protection (IP) code | IP30 |
| Internal | |
| LED indicators | |
| DIN rail mounting | |
| Network | |
| Maximum data transfer rate | 1000 Mbit/s |
| Converter input interface | 10Base-T, 100Base-TX, 1000Base-T |
| Converter output interface | 1000Base-SX |
| Networking standards | IEEE 802.1Q, IEEE 802.3at |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Packet forwarding rate (10 Mbps) | 14880 pps |
| Packet forwarding rate (100 Mbps) | 148880 pps |
| Packet forwarding rate (1 Gbps) | 1488000 pps |
| Jumbo frames support | |
| Auto MDI/MDI-X | |
| Store-and-forward | |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 75 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating altitude | 0 - 3048 m |
| Performance | |
| Maximum transfer distance | 550 m |
| Wavelength | 850 nm |
| Fiber mode structure | Multi-mode |
| Tx power (min) | -9.5 dBmW |
| Tx power (max) | -4 dBmW |
| Rx power (min) | -17 dBmW |
| Rx power (max) | -3 dBmW |
| Ports & interfaces | |
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber ports quantity | 1 |
| Fiber optic connector | SC |
| Power over Ethernet plus (PoE+) ports quantity | 1 |
| Power | |
| Total Power over Ethernet (PoE) budget | 70 W |
| Power over Ethernet (PoE) | |
| Weight & dimensions | |
| Width | 111 mm |
| Depth | 96 mm |
| Height | 35 mm |
| Weight | 748 g |
Questions & answers
What is the delivery time of Allied Telesis AT-IMC2000TP/SC-980 ALLIED TAA 10/100/1000T POE+ to 1000SX/SC Industrial Temp Gigabit Media Converter?
The article Allied Telesis AT-IMC2000TP/SC-980 ALLIED TAA 10/100/1000T POE+ to 1000SX/SC Industrial Temp Gigabit Media Converter is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Allied Telesis AT-IMC2000TP/SC-980 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Allied Telesis AT-IMC2000TP/SC-980 ALLIED TAA 10/100/1000T POE+ to 1000SX/SC Industrial Temp Gigabit Media Converter always at the best possible price. We can give you a discount of 2% on Allied Telesis AT-IMC2000TP/SC-980 ALLIED TAA 10/100/1000T POE+ to 1000SX/SC Industrial Temp Gigabit Media Converter if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
