Yealink DECT Multi-Cell Manager W80DM
|
379,05 EUR |
|
|
( 451,07 EUR incl. VAT ) ≈ £320.30 | ≈ $423.78 plus delivery charges: 53,00 € |
|
| Delivery time from supplier's stock (ca.) 6 workdaysinfo_outline | |
| In Stock: >100 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 1619912 |
| Mfg Part No: | W80DM |
| UPC/EAN: | 6938818305373 |
| Weight: | 0.3 kg |
Further System Telephones DECT from YealinkFurther products in category System Telephones DECT
All products of Yealink
Product information for Yealink W80DM:
The W80DM DECT manager for the Yealink W80 DECT IP multi-cell system manages up to 30 optional W80B base stations. This system offers companies scalability and increased mobility through a seamless handover and roaming solution, a stable communication experience and high usability for a wide range of scenarios. For example, warehouses, hotels, car dealerships, offices, retail establishments and other large areas. In addition, you can configure and manage the entire multi-cell system via the DECT Manager web portal.
Highlights
- DECT Manager in a modern, compact design
- Supports up to 30 W80B base stations
- Seamless handover and roaming
- Supports PoE
- Easy setup and deployment
- DECT base station
- ear category (ElektroG): relevant, category 6: small devices of IT and telecommunications technology, small devices of IT and telecommunications technology B2C
- Mounting type: surface-mounted
- Fastening: table mounting, wall mounting
- Color: white
- Height: 130 mm
- Length/depth: 25.1 mm
- Width : 100 mm
- Yealink SIP-W80DM DECT Manager multi-cell system
- expansion screws
- quick instructions
Product type
Specifications
Basic properties
Scope of delivery
| Antenna | |
| Frequency range (EU) | 1880 - 1900 MHz |
| Frequency range (US) | 1920 - 1930 MHz |
| Maximum indoor range | 50 m |
| Maximum outdoor range | 300 m |
| Call management | |
| Number of parallel conferences | 3 |
| Phonebook capacity (per handset) | 100 entries |
| Number of simultaneous calls (max) | 100 |
| Number of WB calls per base supported (max) | 8 |
| Number of NB calls per base supported (max) | 8 |
| Number of simultaneous calls per handset | 2 |
| Conference call | |
| Anonymous call | |
| Anonymous call rejection | |
| Call waiting | |
| Call forwarding | |
| Caller ID | |
| Remote phonebook | |
| Call transfer | |
| Call hold | |
| Do not disturb function | |
| Switching between calls | |
| Mute function | |
| Speed dialling | |
| Integrated voicemail | |
| Redialing | |
| Message Waiting Indication (MWI) function | |
| Phonebook search/import/export function | |
| Call history | |
| Reset function | |
| Emergency call | |
| Shared Call Appearance (SCA) | |
| System log export | |
| Design | |
| Product colour | White |
| Full duplex | |
| Wall mountable | |
| LED indicators | |
| Logistics data | |
| Products per master (outer) case | 10 pc(s) |
| Master (outer) case gross weight | 3.13 kg |
| Master (outer) case length | 375 mm |
| Master (outer) case width | 336 mm |
| Master (outer) case height | 187 mm |
| Harmonized System (HS) code | 85177900 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 95% |
| Packaging content | |
| Screws included | |
| Quick start guide | |
| Power adapter included | |
| Performance | |
| Number of handsets supported (max) | 100 |
| Number of carrier frequencies | 2 |
| Number of VoIP accounts | 100 |
| Management protocols | TFTP/FTP/HTTP/HTTPS/RPS |
| Supported network protocols | SIP v1 (RFC2543), v2 (RFC3261), SNTP/NTP, VLAN (802.1Q and 802.1P), 802.1x, LLDP, STUN, UDP/TCP/TLS |
| Number of bases supported (max) | 30 |
| Security algorithms | AES, HTTPS, SHA-256, SHA-384, SHA-512, SRTP, TLS |
| Voice codecs | AGC, AJB, AMR-NB, AMR-WB, CNG, G.722, G.726, G.729, OPUS, PCMA, PLC, VAD, iLBC |
| Networking standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3af |
| Wireless synchronization | |
| Hearing aid compatibility | |
| Dual-Tone Multi-Frequency (DTMF) | |
| Keypad lock | |
| XML browser | |
| IPUI registration | |
| User access level | |
| Auto-provision | |
| Over the Air Updates (OTA) | |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN | |
| Power | |
| Input voltage | 100 - 240 V |
| Output voltage | 5 V |
| Output current | 1.2 A |
| Power over Ethernet (PoE) | |
| Weight & dimensions | |
| Dimensions (WxDxH) | 130 x 100 x 25.1 mm |
| Weight | 2.56 kg |
| Package width | 174 mm |
| Package depth | 180 mm |
| Package height | 63 mm |
