Ubiquiti 5GHz P2MP 5GHz Ltu Long Range Client Radio / LTU-LR-EU
|
118,97 EUR 123,29 EUR |
|
|
( 141,57 EUR incl. VAT ) plus delivery charges |
|
| Delivery time on requestinfo_outline | |
| Lieske Part No.: | 1705138 |
|---|---|
| Mfg Part No: | LTU-LR |
| Weight: | 1.36 kg |
Product information for Ubiquiti LTU-LR:
5 GHz PtMP LTU Long-Range Client, works in a PtMP environment with the LTU-Rocket as a base station. 5 GHz, 30+ km connection range
Over 900 Mbps throughput*
Dedicated spectrum analysis radio
Easy to assemble
Technical specifications Mechanical Dimensions 512.5 x 385.75 x 258.3 mm (20.18 x 15.19 x 10.17 inches) Weight Without bracket: 1.36 kg (3 lb)
With bracket: 1.74 kg (3.8 lb) Housing material UV stabilized polycarbonate Mounting Pole bracket (kit included) Wind load 550 N at 200 km/h (123.6 lbf at 125 mph) Wind survivability 200 km/h (125 mph) Hardware Network interface (1) GbE RJ45 port Power method Passive 24V PoE (pairs 4, 5+ 7, 8-) Power supply 24V, 0.5 A Gigabit PoE adapter (included) Supported voltage range 22-26V DC Max. power consumption 8.5W ESD/EMP protection Air/contact: ± 24kV Operating temperature -40 to 60°C (-40 to 140° F) Operating Humidity 5 to 95% non-condensing Certifications CE, FCC, IC Software Modes PtMP CPE, PtP*
*1.5.1 series firmware and later 1.5.x. Services SNMP, SSH, Dynamic DNS, Web Server, Remote Protocol, Ping Watchdog Utilities airView®, Speed Test, Orientation, Discovery, Ping, Traceroute, Cable Test, Constellation Auto Distance Adjustment Yes Auto Power Adjustment Yes Network Bridge/Router* Mode
*The Router mode is only available in PtMP CPE mode. Security Yes Static reporting Yes Management interface Bluetooth management for easy setup via
UISP app WEB interface Minimum software requirements
Any modern iOS™ or Android™ based smartphone with web browser System Maximum throughput 900+ Mbps*
*FW- Version 2.3.0 and above. Encryption WPA2-PSK (AES) Uplink/Downlink Ratio 25/75, 33/67, 50/50 RF Operating Frequency*
US/CA
U-NII-1
U-NII-2A
U-NII-2C
U-NII-3
Worldwide
5150 – 5250 MHz
5250 – 5350 MHz
5470 – 5725 MHz
5725 – 5850 MHz
4800 – 6200 MHz
*Depending on regulatory region. Management radio
worldwide
2400 - 2483.5 MHz Max. wired transmission power 22 dBm (per chain) Channel bandwidth 10/20/30/40/50/60/80/100 MHz*
*FW version 2.3.0 and higher. Antenna gain 26 dBi
Over 900 Mbps throughput*
Dedicated spectrum analysis radio
Easy to assemble
Technical specifications Mechanical Dimensions 512.5 x 385.75 x 258.3 mm (20.18 x 15.19 x 10.17 inches) Weight Without bracket: 1.36 kg (3 lb)
With bracket: 1.74 kg (3.8 lb) Housing material UV stabilized polycarbonate Mounting Pole bracket (kit included) Wind load 550 N at 200 km/h (123.6 lbf at 125 mph) Wind survivability 200 km/h (125 mph) Hardware Network interface (1) GbE RJ45 port Power method Passive 24V PoE (pairs 4, 5+ 7, 8-) Power supply 24V, 0.5 A Gigabit PoE adapter (included) Supported voltage range 22-26V DC Max. power consumption 8.5W ESD/EMP protection Air/contact: ± 24kV Operating temperature -40 to 60°C (-40 to 140° F) Operating Humidity 5 to 95% non-condensing Certifications CE, FCC, IC Software Modes PtMP CPE, PtP*
*1.5.1 series firmware and later 1.5.x. Services SNMP, SSH, Dynamic DNS, Web Server, Remote Protocol, Ping Watchdog Utilities airView®, Speed Test, Orientation, Discovery, Ping, Traceroute, Cable Test, Constellation Auto Distance Adjustment Yes Auto Power Adjustment Yes Network Bridge/Router* Mode
*The Router mode is only available in PtMP CPE mode. Security Yes Static reporting Yes Management interface Bluetooth management for easy setup via
UISP app WEB interface Minimum software requirements
Any modern iOS™ or Android™ based smartphone with web browser System Maximum throughput 900+ Mbps*
*FW- Version 2.3.0 and above. Encryption WPA2-PSK (AES) Uplink/Downlink Ratio 25/75, 33/67, 50/50 RF Operating Frequency*
US/CA
U-NII-1
U-NII-2A
U-NII-2C
U-NII-3
Worldwide
5150 – 5250 MHz
5250 – 5350 MHz
5470 – 5725 MHz
5725 – 5850 MHz
4800 – 6200 MHz
*Depending on regulatory region. Management radio
worldwide
2400 - 2483.5 MHz Max. wired transmission power 22 dBm (per chain) Channel bandwidth 10/20/30/40/50/60/80/100 MHz*
*FW version 2.3.0 and higher. Antenna gain 26 dBi
