TP-LINK Switch SG2428P 24xGBit/4xSFP Managed PoE+ (250W)
|
302,24 EUR |
|
|
( 359,67 EUR incl. VAT ) ≈ £256.90 | ≈ $339.42 plus delivery charges: 53,00 € |
|
| Delivery time from supplier's stock (ca.) 6 workdaysinfo_outline | |
| In Stock: >50 pieces | |
| End-Of-Life: | 22. Aug 2026 |
|---|---|
| Lieske Part No.: | 1607134 |
| Mfg Part No: | TL-SG2428P |
| UPC/EAN: | 6935364030650 |
| Weight: | 4.79 kg |
| Type: | PERP |
Further Miscellaneous from TP-LinkFurther products in category Miscellaneous
All products of TP-Link
Product information for TP-Link TL-SG2428P:
Expand your existing network with the TP-Link TL-SG2428P 24-Port and 4 SFP Slots Gigabit Smart Switch. Thanks to PoE+, it works with all IEEE 802.3af/at devices and delivers a total PoE output of up to 250 watts.
Highlights
- 24 IEEE802.3at/af-compliant Gigabi PoE+ ports with a total power of up to 250 W
- 4 Gigabit SFP slots enable high-speed connections
- Zero-touch provisioning (ZTP), centralized cloud management and intelligent monitoring
- Cloud access and The Omada app allows for very convenient, easy management
- IP MAC port binding, ACL, port security, DoS Defend, Storm Control, DHCP Snooping, 802.1X, Radius Authentication, and much more
- Optimized voice and video applications : L2/L3/L4 QoS and IGMP snooping
- Switch
- ear category (ElektroG): relevant, Category 6: small IT and telecommunications devices, Small IT and telecommunications devices B2C
- Switch type: Access
- Total number of copper ports: 24
- Total number of fiber optic ports: 4
- Total number of PoE ports: 24
- Bandwidth: 10/100/1000 MBit/s
- PoE budget: 250 W
- Switch manageable: Yes
- Mounting type: 48,3 cm ( 19 inch ) rack mount
- Color: Black
- Length/depth: 220 mm
- Width: 440 mm
- TP-Link TL-SG2428P 24-Port Gigabit PoE+ L2 Smart Switch 4xSFP
- Power cable
- Rackmount Kit
- Rubber feet
- Installation Guide
Product type
Specifications
Connections
Functions
Basic features
Scope of delivery
| Certificates | |
| Certification | CE, FCC, RoHS |
| Data transmission | |
| Switching capacity | 56 Gbit/s |
| Forwarding rate | 41.66 Mpps |
| MAC address table | 8000 entries |
| Number of queues | 8 |
| Jumbo frames | 9000 |
| Packet buffer memory | 4.1 MB |
| Jumbo frames support | |
| Design | |
| Form factor | 1U |
| Product colour | Black |
| Number of fans | 2 fan(s) |
| Rack mounting | |
| Management features | |
| Switch type | Managed |
| Switch layer | L2/L2+ |
| MIB support | Y |
| Quality of Service (QoS) support | |
| Web-based management | |
| ARP inspection | |
| System event log | |
| Multicast features | |
| Multicast support | |
| Network | |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Copper ethernet cabling technology | 10BASE-T, 1000BASE-T |
| Cable types supported | Cat3, Cat4, Cat5, Cat5e |
| Virtual LAN features | MAC address-based VLAN, Protocol-based VLAN, Voice VLAN |
| Number of VLANs | 4000 |
| 10G support | |
| Port mirroring | |
| Flow control support | |
| Link aggregation | |
| Broadcast storm control | |
| Rate limiting | |
| Spanning tree protocol | |
| VLAN support | |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Heat dissipation | 1052.94 BTU/h |
| Optical fiber | |
| Fiber ethernet cabling technology | 1000BASE-X |
| Packaging content | |
| Cables included | AC |
| User guide | |
| Rack mount kit | |
| Performance | |
| Firmware upgradeable | |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity | 24 |
| SFP module slots quantity | 4 |
| Power | |
| Power source | AC |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power consumption (max) | 301.1 W |
| Power supply included | |
| Power over Ethernet (PoE) | |
| Power over Ethernet plus (PoE+) ports quantity | 24 |
| Power over Ethernet (PoE) power per port | 30 W |
| Total Power over Ethernet (PoE) budget | 250 W |
| Power over Ethernet (PoE) | |
| Protocols | |
| Management protocols | SNMPv1/v2c/v3, SNTP |
| Security | |
| DHCP features | DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client |
| Security algorithms | HTTPS, SNMP, SNMPv2, SNMPv3, SSH, SSH-2, SSL/TLS |
| Authentication type | RADIUS |
| Queue scheduling algorithms | SP, WRR+SP, Weighted Round Robin (WRR) |
| Access Control List (ACL) | |
| IGMP snooping | |
| SSH/SSL support | |
| BPDU filtering/protection | |
| IP-MAC-Port binding | |
| Weight & dimensions | |
| Width | 440 mm |
| Depth | 220 mm |
| Height | 44 mm |
Please note...
We have listed this article as 'end-of-life', which means that it will only be sold until it is completely sold out ! Please mind that we cannot guarantee you, you will receive the article, although it may be betokened as available. You can find the date from when the article was marked end-of-life to the top.
