TP-LINK Switch TL-SG1428PE 24xGBit PoE+ (250W)/2xGBit/2xSFP Unmanaged/Easy Smart PoE Switch content_copy

TP-Link's TL-SG1428PE is an easy-to-use, high-performance, general-purpose PoE switch. The total PoE power budget of 250 watts for the 24 Gigabit PoE+ ports offers a wide range of applications. It is ideal for surveillance systems, offices and small businesses. Furthermore, it is fully compatible with IP cameras, access points, IP phones, computers and printers.

Highlights

• 24 Gigabit PoE+ ports, 2 Gigabit Non-PoE ports and 2 Gigabit SFP ports
• Up to 250 watt PoE power budget
• Ideal for surveillance systems and small/medium businesses
• Priority mode guarantees the quality of sensitive applications such as video surveillance
• PoE Auto Recovery enables the system to heal itself
• Intelligent power management can protect the switch from overload
• QoS ensures smooth Internet surfing
• IGMP snooping can optimize data traffic for IPTV

Product type

• Switch
• ear category (ElektroG): relevant, category 6 : small IT and telecommunications technology devices, small IT and telecommunications technology devices B2C

Specifications

• Switch type: Access

Connections

• Total number of copper ports: 26
• Total number of fiber optic ports: 2
• Bandwidth: 10/100/ 1000 MBit/s
• PoE budget: 250 W
• Main port type: Copper

Functions

• Mounting type: Desktop, 48,3 cm ( 19 inch ) rack mount

Basic features

• Color: Black
• Height: 44 mm
• Length/Depth: 220 mm
• Width: 440 mm

Scope of delivery

• TP-Link TL-SG1428PE 28-Port Gigabit Easy Smart Switch with 24-Port PoE+
• Power cable
• Installation instructions
• Rackmount Kit
• Rubber feet

Certificates
Certification	CE, FCC, RoHS
Data transmission
Switching capacity	56 Gbit/s
Forwarding rate	41.7 Mpps
MAC address table	8000 entries
Number of queues	4
Jumbo frames	10000
Packet buffer memory	4.1 MB
Store-and-forward
Jumbo frames support
Design
Form factor	1U
Product colour	Black
Number of fans	2 fan(s)
Rack mounting
Logistics data
Harmonized System (HS) code	85176990
Management features
Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support
Web-based management
Multicast features
Multicast support
Network
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Cable types supported	Cat3, Cat4, Cat5, Cat5e, Cat6
Virtual LAN features	Port-based VLAN, Tagged VLAN
Number of VLANs	32
10G support
Port mirroring
Flow control support
Link aggregation
Broadcast storm control
Rate limiting
Auto MDI/MDI-X
Auto-negotiation
VLAN support
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 90%
Optical fiber
Fiber ethernet cabling technology	1000BASE-X
Packaging content
Cables included	AC
User guide
Rack mount kit
Packaging data
Package width	336 mm
Package depth	528 mm
Package height	100 mm
Package weight	2.29 kg
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	26
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity	26
SFP module slots quantity	2
Power
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1039.03 W
Power supply included
Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity	24
Power over Ethernet (PoE) power per port	30 W
Total Power over Ethernet (PoE) budget	250 W
Power over Ethernet (PoE)
Security
Security algorithms	SNMP, SNMPv2, SNMPv3
IGMP snooping
Weight & dimensions
Width	440 mm
Depth	220 mm
Height	44 mm

---
