TP-Link Switch TL-SG1210P 10-Port Gigabit PoE content_copy

Ports 1-8 of the switch support the PoE (Power over Ethernet) function. These PoE ports can automatically detect and power these IEEE 802.3af/at compliant Powered Devices (PDs).
Rugged, compact metal housing with desktop/wall mount design to meet your needs in any environment. In addition, the fanless design ensures quiet operation.

Highlights

• 9 RJ45 ports with 10/100/1000 Mbps, 1 Gigabit SFP port
• With 8 PoE+ ports, transmits data and power over a single cable
• Works with IEEE 802.3af/at compliant PDs extends home and office network
• 802.1p/DSCP QoS enables smooth latency-sensitive traffic
• High PoE power budget with up to 30W for each PoE port and 63W for all PoE ports
• Easy to use, no configuration and installation required

Product type

• Switch
• ear category (ElektroG): relevant, Category 6: small IT and telecommunications technology devices, small IT and telecommunications technology devices B2C

Specifications

• Switch type: Access

Connections

• Number of copper ports Total: 9
• Total number of fiber optic ports: 1
• Total number of PoE ports: 8
• Bandwidth: 10/100/1000 MBit/s
• PoE budget: 63 W
• Main port type: Copper

Functions

• Mounting type: Desktop

Basic features

• Color: Black
• Height: 26 mm
• Length/Depth: 126 mm
• Width: 209 mm

Scope of delivery

• TL-SG1210P
• Power supply
• Installation instructions

Certificates
Certification	CE, FCC, RoHS
Data transmission
Switching capacity	20 Gbit/s
MAC address table	4000 entries
Store-and-forward
Design
Product colour	Grey
Housing material	Metal
LED indicators
Wall mountable
Logistics data
Harmonized System (HS) code	85176990
Management features
Switch type	Unmanaged
Quality of Service (QoS) support
Network
Networking standards	IEEE 802.1p, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
10G support
Auto MDI/MDI-X
Auto-negotiation
MAC address auto-learning supported
MAC address auto-aging supported
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 90%
Heat dissipation	266.42 BTU/h
Optical fiber
Fiber ethernet cabling technology	1000BASE-X
Fiber type	Single-mode
Packaging content
Cables included	AC
Quick start guide
User guide
Manual
Performance
Fanless
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	9
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity	9
SFP module slots quantity	1
Power
DC input voltage	53.5 V
Input current	1.31 A
Power consumption (typical)	7.11 W
Power consumption (max)	78.13 W
Power supply included
Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity	8
Total Power over Ethernet (PoE) budget	63 W
Power over Ethernet (PoE)
Security
IGMP snooping
Weight & dimensions
Width	209 mm
Depth	126 mm
Height	26 mm

---
