TP-LINK TL-SG1016DE 16 Ports Manageable Ethernet Switch - 16 x Network (RJ-45) Ports
|
61,36 EUR 63,79 EUR |
|
|
( 73,02 EUR incl. VAT ) ≈ £51.67 | ≈ $68.91 plus delivery charges: 53,00 € |
|
| Delivery time from supplier's stock (ca.) 7 workdaysinfo_outline | |
| In Stock: >50 pieces | |
| End-Of-Life: | 14. Sep 2026 |
|---|---|
| Datasheet: | file_download Download |
| Lieske Part No.: | 682615 |
| Mfg Part No: | TL-SG1016DE |
| UPC/EAN: | 6935364021269 |
| Weight: | 2 kg |
Further up to 16 ports from TP-LinkFurther products in category up to 16 ports
All products of TP-Link
Product information for TP-Link TL-SG1016DE:
Der 16-Port-Gigabit-Easy-Smart-Switch TL-SG1016DE bietet kleinen und mittelgroßen Unternehmen eine einfache Möglichkeit, den Übergang zum Gigabit-Ethernet zu wagen. Dem Administrator bietet der Switch Basisfunktionen wie Portmirroring, Loopback-Erkennung und Kabeldiagnose. Zur Trafficoptimierung steht Ihnen VLAN (port- und tagbasierend) zur Verfügung. Weiterhin verbessern port- und tagbasierendes VLAN die Sicherheit, da Ihr Netz dadurch segmentiert wird. Darüber hinaus sparen Sie mit der innovativen, energieeffizienten Technik des TL-SG1016DE bis zu 40% Energie ein, womit dieser auch eine umweltfreundliche Lösung für Ihr Geschäftsnetz darstellt.
Highlights
- 16 Ports mit Autoabstimmung
- Die innovative Green IT spart bis zu 40% Energie ein
- Unterstützt IEEE802.3x-Flusskontrolle für zuverlässige Datentransfers
- 10k-Jumbo-Frames verbessern die Leistung der Übertragung großer Datenmengen
- Effektive Netzüberwachung durch Portmirroring, Loopback-Erkennung und Kabeldiagnose
- Port- und tagbasierendes QoS erlaubt den flüssigen Ablauf von latenzempfindlichen Anwendungen
- Zahlreiche VLAN-Features verbessern die Sicherheit durch Trafficsegmentierung
- IGMP-Snooping optimiert die Performance bei Verwendung von Multicast-Anwendungen
- 16 Ports Cu 10/100/1000
- 48,3 cm ( 19 inch ) Montage
- Lüfterlos
- Layer 2 Funktionen - 802.1q (VLAN-Tagging)
- Max. Energieverbrauch 12,55 W (ohne PoE)
- 19-Zoll Rackmontage
- Tischmontage
- Color: Black
- Höhe: 44 mm
- Breite: 294 mm
- Tiefe: 180 mm
- Produkttyp: Switch
- TL-SG1016DE
- Stromversorgungskabel
- Schnellinstallationsanleitung
- CD
- Rackmontagekit
- Gummifüßchen
Switch
Basic Properties
Delivery
| Certificates | |
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS |
| Data transmission | |
| Switching capacity | 32 Gbit/s |
| Forwarding rate | 23.8 Mpps |
| MAC address table | 8000 entries |
| Number of queues | 4 |
| Jumbo frames | 9000 |
| Packet buffer memory | 0.512 MB |
| Store-and-forward | |
| Jumbo frames support | |
| Design | |
| Form factor | 1U |
| Product colour | Black |
| Housing material | Metal |
| Rack mounting | |
| LED indicators | |
| Management features | |
| Switch type | Managed |
| Switch layer | L2 |
| Quality of Service (QoS) support | |
| Network | |
| Networking standards | IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
| Copper ethernet cabling technology | 100BASE-TX, 100BASE-T, 1000BASE-T |
| Cable types supported | Cat3, Cat5, Cat6 |
| Virtual LAN features | Port-based VLAN, Tagged VLAN |
| Number of VLANs | 32 |
| 10G support | |
| Port mirroring | |
| Flow control support | |
| Link aggregation | |
| Broadcast storm control | |
| Rate limiting | |
| Auto MDI/MDI-X | |
| Auto-negotiation | |
| VLAN support | |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Heat dissipation | 34.52 BTU/h |
| Packaging content | |
| Cables included | AC |
| User guide | |
| Rack mount kit | |
| Packaging data | |
| Package type | Box |
| Package width | 250 mm |
| Package depth | 400 mm |
| Package height | 80 mm |
| Package weight | 1.98 kg |
| Resource CD | |
| Performance | |
| Compatible operating systems | Windows |
| Maximum cable length | 100 m |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity | 16 |
| Power connector | AC-in jack |
| Power | |
| Power source | AC |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power consumption (max) | 19.15 W |
| Power supply included | |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | |
| Security | |
| IGMP snooping | |
| Sustainability | |
| Sustainability compliance | |
| Weight & dimensions | |
| Width | 284 mm |
| Depth | 180 mm |
| Height | 44 mm |
