TP-LINK Switch TL-SG1008P 8xGBit Unmanaged (4xPoE)
|
43,65 EUR |
|
|
( 51,94 EUR incl. VAT ) ≈ £37.02 | ≈ $48.93 plus delivery charges: 53,00 € |
|
| in stockinfo_outline | |
| End-Of-Life: | 14. Sep 2026 |
|---|---|
| Datasheet: | file_download Download |
| Lieske Part No.: | 682330 |
| Mfg Part No: | TL-SG1008P |
| UPC/EAN: | 6935364021160 |
| Weight: | 1.004 kg |
Further Miscellaneous from TP-LinkFurther products in category Miscellaneous
All products of TP-Link
Product information for TP-Link TL-SG1008P:
Der 8-Port-Gigabit-Desktop-PoE-Switch TL-SG1008P ermöglicht eine nahtlose Netzwerkverbindung. Er kombiniert Fast-Ethernet- mit Gigabit-Ethernet-Netzwerkfähigkeiten.
Highlights
- PoE-Leistung: Bis zu 15,4 W pro PoE-Port
- PoE-Leistung für alle PoE-Ports: Bis zu 53W
- Unterstützt IEEE802.3af-kompatible PDs
- IEEE802.3x-Flusskontrolle für Vollduplex und Backpressure für Halbduplex
- MAC-Adressen-Tabelle für 1000 Einträge mit Auto-Learning und Auto-Aging
- LED-Anzeigen für Leistung, Link, Aktivität und Geschwindigkeit
- Versorgung über externen Spannungsadapter
- 8 Ports Cu 10/100/1000
- 4 PoE Ports nach 802.3af
- Lüfterlos
- PoE 802.3af
- maximale PoE Kapazität 53 W
- Max. Energieverbrauch 3,3 W (ohne PoE)
- Max. Ernergieverbrauch 63 W mit PoE
- Tischmontage
- Color: Black
- Höhe: 27 mm
- Breite: 98 mm
- Tiefe: 171 mm
- Produkttyp: Switch
- TL-SG1008P
- Spannungsadapter
- Manual
Switch
Basic Properties
Delivery
| Certificates | |
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS |
| Data transmission | |
| Switching capacity | 16 Gbit/s |
| Forwarding rate | 11.904 Mpps |
| MAC address table | 4000 entries |
| Jumbo frames | 16000 |
| Store-and-forward | |
| Jumbo frames support | |
| Design | |
| Product colour | Grey |
| Housing material | Metal |
| Rack mounting | |
| Stackable | |
| LED indicators | |
| Management features | |
| Switch type | Managed |
| Quality of Service (QoS) support | |
| Network | |
| Networking standards | IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
| Copper ethernet cabling technology | 1000BASE-T, 100BASE-TX, 10BASE-T |
| Cable types supported | Cat3, Cat4, Cat5, Cat5e |
| 10G support | |
| Flow control support | |
| Auto MDI/MDI-X | |
| Auto-negotiation | |
| MAC address auto-learning supported | |
| MAC address auto-aging supported | |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Heat dissipation | 225.75 BTU/h |
| Packaging content | |
| Cables included | AC |
| User guide | |
| Packaging data | |
| Package type | Box |
| Package width | 223 mm |
| Package depth | 280 mm |
| Package height | 68 mm |
| Package weight | 1.25 kg |
| Performance | |
| Maximum cable length | 100 m |
| Fanless | |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity | 8 |
| Power connector | DC-in jack |
| Power | |
| Power source | DC/PoE |
| Number of power supply units | 1 |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| DC input voltage | 53.5 V |
| Input current | 1.31 A |
| Power consumption (max) | 75 W |
| Power supply included | |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) ports quantity | 4 |
| Total Power over Ethernet (PoE) budget | 64 W |
| Power over Ethernet (PoE) | |
| Security | |
| IGMP snooping | |
| Sustainability | |
| Sustainability compliance | |
| Weight & dimensions | |
| Width | 171 mm |
| Depth | 98 mm |
| Height | 27 mm |
