TP-LINK Switch SX3032F 32x10G SFP+ L2+Managed Omada SDN
|
949,05 EUR |
|
|
( 1.129,37 EUR incl. VAT ) ≈ £806.69 | ≈ $1,065.78 plus delivery charges: 83,00 € |
|
| Delivery time from supplier's stock (ca.) 6 workdaysinfo_outline | |
| In Stock: >5 pieces | |
| Lieske Part No.: | 1066857 |
|---|---|
| Mfg Part No: | SX3032F(UN) |
| UPC/EAN: | 4895252504477 |
| Weight: | 6.815 kg |
| Type: | CPNT |
Product information for TP-Link SX3032F(UN):
Maximale Geschwindigkeit und volle Kontrolle: Der TP-Link Omada SX3032F ist ein leistungsstarker 32-Port 10G SFP+ L2+ Managed Switch, ideal für anspruchsvolle Netzwerke. Mit hoher Bandbreite, umfassenden Managementfunktionen und Omada Cloud-Integration bietet er eine zuverlässige, skalierbare Lösung für Unternehmen und Rechenzentren. Perfekt für schnelle Datenübertragung, reibungsloses Streaming und nahtlose Konnektivität!
Highlights
- 32× 10-Gbit/s-SFP+-Steckplätze
- 640 Gbit/s Switching-Kapazität
- Zwei interne, fest verbaute Stromversorgungsmodule sichern sich gegenseitig ab
- Zentralisiertes Cloud-Management über das Web oder die Omada-App
- Eigenständige Verwaltung über Web, CLI, SNMP und RMON
- Statisches Routing hilft, internen Datenverkehr effizienter zu lenken
- VLAN, ACL, QoS, IGMP Snooping, OAM und DDM
- ERPS unterstützt schnellen Schutz und Wiederherstellung in einer Ringtopologie
- Robustes Metallgehäuse und rackmontierbares Design
Produkttyp
- Switch
- ear-Kategorie (ElektroG): relevant, Kategorie 6: kleine Geräte der IT- und TK-Technik, Kleine Geräte der Informations- und Telekommunikationstechnik, die in privaten Haushalten genutzt werden können
Spezifikationen
- Lüfter integriert
- Switch-Art: Access
- Switchingkapazität: 640 GBit/s (Gbps)
Versand
- WEEE: 85565951
Anschlüsse
- Glasfaserports (fest verbaut oder SFP) gesamt: 32
- Anschlüsse Highlights: 1× RJ45-Konsolenport; 1× Micro-USB-Konsolenport
- Bandbreite: 100/1000/10G-Base-T
- Konsolenport
- Hauptporttyp: Glasfaser
- Anzahl SFP+ Ports (10G): 32
Funktionen
- Switch managebar: Ja
- Montageart: 48,3 cm ( 19 inch ) Rackmontage
- IGMP
Stromversorgung
- Netzteil: integriert
Grundeigenschaften
- Farbe: Schwarz
- Höhe: 44 mm
- Länge/Tiefe: 330 mm
- Breite: 440 mm
Lieferumfang
- TP-Link Omada SX3032F 32-Port 10GE SFP+ L2+ Managed Switch
- 2x Netzkabel
- Schnellinstallationsanleitung
- Rackmontagesatz
- Gummifüße
| Certificates | |
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS |
| Data transmission | |
| Switching capacity | 640 Gbit/s |
| Forwarding rate | 240 Mpps |
| MAC address table | 32000 entries |
| Number of queues | 8 |
| Number of static routes | 128 |
| Number of IP interfaces | 128 |
| Jumbo frames | 9 |
| Packet buffer memory | 24 MB |
| Static route | |
| Jumbo frames support | |
| Design | |
| Product colour | Black |
| Number of fans | 2 fan(s) |
| Rack mounting | |
| Redundant fans support | |
| Management features | |
| Switch type | Managed |
| Switch layer | L2+ |
| MIB support | • MIB II (RFC1213) • Interface MIB (RFC2233) • Ethernet Interface MIB (RFC1643) • Bridge MIB (RFC1493) • P/Q-Bridge MIB (RFC2674) • RMON MIB (RFC2819) • RMON2 MIB (RFC2021) • Radius Accounting Client MIB (RFC2620) • Radius Authentication Client MIB (RFC2618) • Remote Ping, Traceroute MIB (RFC2925) • Support TP-Link private MIB |
| Quality of Service (QoS) support | |
| Cloud-managed | |
| ARP inspection | |
| Configuring Location Settings (CLI) | |
| Multicast features | |
| Number of multicast groups filtered | 4000 |
| Multicast support | |
| Multicast Listener Discovery (MLD) snooping | |
| Network | |
| Networking standards | IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1x, IEEE 802.3ah, IEEE 802.3x |
| IPv4 routes | 48 |
| IPv6 routes | 48 |
| Virtual LAN features | Protocol-based VLAN, SSID-based VLAN assignment, Tagged VLAN, VLAN mapping, Voice VLAN |
| Number of VLANs | 30 |
| Port mirroring | |
| Flow control support | |
| Link aggregation | |
| Broadcast storm control | |
| Rate limiting | |
| Spanning tree protocol | |
| VLAN support | |
| Operational conditions | |
| Operating temperature (T-T) | -5 - 45 °C |
| Storage temperature (T-T) | 40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Packaging content | |
| Cables included | Power |
| Quick start guide | |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 1 |
| Installed SFP+ modules quantity | 32 |
| Console port | RJ-45/Micro-USB |
| Power | |
| Power source | AC |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power consumption (max) | 49.4 W |
| Power supply included | |
| Protocols | |
| IPv4 & IPv6 features | Dual stack IPv4/IPv6, ICMPv6, IPv6 TFTP |
| GARP VLAN Registration Protocol (GVRP) | |
| IP Source Guard (IPSG) | |
| Security | |
| DHCP features | DHCP relay, DHCP server, DHCPv6 snooping |
| Authentication | MAC-based authentication, Port-based authentication |
| Authentication type | AAA, TACACS+ |
| Queue scheduling algorithms | Priority queuing (PQ), SP, Weighted Round Robin (WRR) |
| Access Control List (ACL) | |
| IGMP snooping | |
| Static port security | |
| SSH/SSL support | |
| Loop protection | |
| IP-MAC-Port binding | |
| Password protection | |
| Weight & dimensions | |
| Width | 440 mm |
| Depth | 330 mm |
| Height | 44 mm |
