TP-LINK SM9110-SR4 Omada 100GBASE-SR4 QSFP28 Transceiver
|
-10% 101,49 EUR 113,05 EUR |
|
|
( 120,77 EUR incl. VAT ) ≈ £85.45 | ≈ $113.97 plus delivery charges: 53,00 € |
|
| Delivery time from supplier's stock (ca.) 6 workdaysinfo_outline | |
| In Stock: >25 pieces | |
| End-Of-Life: | 19. Aug 2026 |
|---|---|
| Datasheet: | file_download Download |
| Lieske Part No.: | 122588 |
| Mfg Part No: | SM9110-SR4(UN) |
| UPC/EAN: | 8885020625493 |
| Weight: | 0.81 kg |
| Type: | PERP |
Product information for TP-Link SM9110-SR4(UN):
Steigern Sie die Leistungsfähigkeit Ihres Netzwerks mit dem TP-Link Omada SM9110-SR4. Dieser 100GBASE-SR4 QSFP28 Transceiver bietet ultraschnelle Datenübertragungen von bis zu 100 Gbps über Multimode-Glasfaserverbindungen. Mit einer Reichweite von bis zu 100?m auf OM4-Fasern und Unterstützung für Digital Diagnostic Monitoring (DDM) gewährleistet er zuverlässige Performance und einfache Wartung. Dank Hot-Plug-Funktionalität und breitem Temperaturbereich lässt sich der SM9110-SR4 flexibel in bestehende Netzwerkinfrastrukturen integrieren. Ideal für Unternehmen, die auf zukunftssichere Technologie und höchste Effizienz setzen.
Highlights
- 100GBASE-SR4 Multimode-QSFP28-Transceiver
- Unterstützt Digital Diagnostic Monitoring (DDM)
- Bis zu 100 m Übertragungsdistanz
- Hot-Plug-fähig mit maximaler Flexibilität
- Großer Betriebstemperaturbereich
- Kompatibel mit 100G/40G Quad Small Form-Factor Pluggable 28 (QSFP28)
Produkttyp
- Netzwerk Switch Modul
- ear-Kategorie (ElektroG): relevant, Kategorie 6: kleine Geräte der IT- und TK-Technik, Kleine Geräte der Informations- und Telekommunikationstechnik, die in privaten Haushalten genutzt werden können
Spezifikationen
- Einsatzgebiet: Indoor
Versand
- WEEE: 85565951
Anschlüsse
- Bandbreite: 100G-Base-T
Datenübertragung
- SFP-Standard: QSFP28
Grundeigenschaften
- Farbe: Silber
- Höhe: 11.7 mm
- Länge/Tiefe: 124 mm
- Breite: 18.35 mm
Lieferumfang
- TP-Link Omada SM9110-SR4
- Installationsanleitung
| Certificates | |
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS |
| Certification | QSFP28 MSA, SFF-8665, SFF-8636, SFF-8436, CPRI, eCPRI, TCP/IP |
| Features | |
| Product colour | Metallic |
| Form factor | QSFP28 |
| Plug and Play | |
| Hot-swap | |
| Logistics data | |
| Country of origin | China |
| Operational conditions | |
| Minimum operating temperature | 0 °C |
| Maximum operating temperature | 70 °C |
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 0 - 85% |
| Storage relative humidity (H-H) | 0 - 85% |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Packaging data | |
| User guide | |
| Performance | |
| SFP transceiver type | Fiber optic |
| Maximum data transfer rate | 100000 Mbit/s |
| Interface type | QSFP28 |
| Fiber optic connector | MPO-12, MTP |
| Fiber cable diameters supported (core/cladding) | 50/125 µm |
| SFP transceiver standard | SR4 |
| Maximum transfer distance | 150 m |
| Wavelength | 850 nm |
| Tx power (min) | -8.4 dBmW |
| Tx power (max) | 2.4 dBmW |
| Ethernet interface type | 40 Gigabit Ethernet, 100 Gigabit Ethernet |
| Networking standards | IEEE 802.3ba, IEEE 802.3bm |
| Fiber ethernet cabling technology | 40GBASE, 100GBASE |
| Single-mode fiber (SMF) supported | |
| Multi-mode fiber (MMF) supported | |
| Digital Diagnostics Monitoring (DDM) | |
| Power | |
| Input voltage | 3.3 V |
| Weight & dimensions | |
| Width | 124 mm |
| Depth | 18.4 mm |
| Height | 11.7 mm |
Please note...
We have listed this article as 'end-of-life', which means that it will only be sold until it is completely sold out ! Please mind that we cannot guarantee you, you will receive the article, although it may be betokened as available. You can find the date from when the article was marked end-of-life to the top.
Questions & answers
What is the delivery time of TP-LINK SM9110-SR4 Omada 100GBASE-SR4 QSFP28 Transceiver?
The article TP-LINK SM9110-SR4 Omada 100GBASE-SR4 QSFP28 Transceiver is currently in stock
According to our experience the article is ready for dispatch within 6 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of TP-Link SM9110-SR4(UN) to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you TP-LINK SM9110-SR4 Omada 100GBASE-SR4 QSFP28 Transceiver always at the best possible price. We can give you a discount of 2% on TP-LINK SM9110-SR4 Omada 100GBASE-SR4 QSFP28 Transceiver if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
