TP-Link WL-AP Access Point EAP110 (300MBit/POE) content_copy

"159TP-LINK951 's Business Access Point EAP110 provides a flexible, easy to install and manage business-class WLAN solution with sophisticated safety technology. The central management software facilitate the WLAN configuration and management. In addition, the EAP110 has a user authentication portal and an automatic radio frequency management and making it ideal for professional use in corporate environments, universities, hotels and shopping centers.

Highlights

• Controller software for centralized WLAN management of hundreds of Access Points
• Supports passive PoE (Power over Ethernet) for flexible installation
• Simple wall or ceiling mounting
• login portal to authenticate your wireless guest (eg in hotels)
• Network Security thanks to WPA / WPA2-Enterprise, 802.1x with RADIUS authentication and detection of faulty APs> antenna characteristics
• WIFI

Interfaces

• WIFI
• Wi-Fi IEEE 802.11b
• IEEE 802.11g wireless standard
• WLAN IEEE 802.11n standard> Data Transfer - WEP - WPA - WPA2 - up to 300 Mbit / s transfer rate> System Connections - Number of Ethernet ports 10/100 Mbit / s: 1

Basic Properties

• Color white
• Height: 47.5 mm
• Width: 180 mm
• Depth: 180 mm> Technical description - Controller software for centralized WLAN management of hundreds EAPs - Supports passive PoE (Power over Ethernet) for simple, low cost installation - User-friendly design, easy to install on walls or ceilings - up to 300 Mbit / s wireless speed - Simple user authentication over the captive portal - WPA / WPA2-Enterprise, 802.1x with RADIUS and detection of faulty Access Points for Network Security - Multi-SSID mode for various User Groups - Radio Frequency Management for automatic adjustment of channel and transmit power - load balancing for best performance, even in large networks - Compatible with all 802.11b / g / n devices - Housing of flame-resistant Low-Smoke Zero-Halogen (LSZH) material - More flexibility by offering multiple operating modes, such as managed-AP and standalone AP - QoS prioritizes the data of voice and video applications - Prevents air vent design, dust from accumulating on the board, thus providing a long, trouble-free operation> delivery - 300Mbit / s WLAN Access Point for ceiling mounting EAP110 - adapter for passive PoE - Power adapter - mounting set - CD
• Installation Instructions

Antenna
Antenna type	Internal
Antenna direction type	Omni-directional
Antennas quantity	2
Antenna gain level (max)	4 dBi
Certificates
Certification	FCC, RoHS
Design
Placement	Ceiling, Wall
Product colour	White
LED indicators	Power
Reset button
Features
Maximum data transfer rate	300 Mbit/s
Maximum data transfer rate (2.4 GHz)	300 Mbit/s
Ethernet LAN data rates	10,100 Mbit/s
Frequency band	2.4 - 2.4835 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x
Cabling technology	10/100Base-T(X)
Virtual LAN features	SSID-based VLAN assignment
Transmitting power (CE)	21 dBm
Receiver sensitivity	300M: -71dBm@10% PER 150M: -75dBm@10% PER 54M: -78dBm@10% PER 11M: -93dBm@8% PER 6M: -92dBm@10% PER 1M: -96dBm@8% PER
2.4 GHz
5 GHz
Automatic channel selection
Wi-Fi Multimedia (WMM)/(WME)
VLAN support
Rate limiting
Wireless isolation
Quality of Service (QoS) support
Logistics data
Harmonized System (HS) code	85176990
Management features
Web-based management
Syslog
Operational conditions
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90%
Packaging content
Quantity per pack	1 pc(s)
Cables included	AC
PoE adapter included
Mounting kit
Quick start guide
Packaging data
Package type	Box
Ports & interfaces
Ethernet LAN (RJ-45) ports	1
Power
AC input voltage	24 V
Power consumption (typical)	2.8 W
Power over Ethernet (PoE)
Security
Security algorithms	64-bit WEP, 128-bit WEP, 152-bit WEP, HTTPS, SNMP, SNMPv2, SSH, WPA, WPA-PSK, WPA2-Enterprise, WPA2-PSK
Service Set Identifier (SSID) features	Multiple SSIDs
Number of SSID supported	8
MAC address filtering
Remote Authentication Dial-In User Service (RADIUS)
Access Control List (ACL)
Weight & dimensions
Width	189.4 mm
Depth	172.3 mm
Height	29.5 mm

---
