Schneider Electric BMXAMI0800 8 channel analog input module,

This analog non-isolated input module is part of the Modicon X80 range, a range of common input/output and communication modules, power supplies and module carriers for Modicon M340 and Modicon M580. This product consists of 8 input channels. This product meets TC treatment requirements (treatment for all climates) and can operate in a temperature range of 0°C to +60°C/32°F to 140°F. Modicon X80 modules provide a uniform environment for the deployment of I/O modules in automation architectures by reducing spare parts inventory, maintenance and training costs. There is no isolation between channels. It is equipped with a 28-pin connector for electrical connection. This product has an IP20 protection class and offers an MTBF of 1,723,151 hours. This module meets the requirements of applications in transportation, water and wastewater, consumer packaged goods, mining, minerals, metals, power generation, energy and chemicals, and data centers. This product is certified by CE, UL, CSA, RCM, EAC, UKCA and Merchant Marine and complies with EN 61000-6-5 and EN 61850-3. This module is compatible with Modicon M340, M580 (Local or Remote I/O) PLCs with a removable 28-pin cage, screw terminal or spring clamp terminal block. The product must be installed in the module carrier and secured with 2 screws.
