Schmersal 101184365 Safety Sensors, BNS260-02ZG-ST-R

The AZM201BZ-ST-T-AS-P RFID safety switch provides an advanced solution for securing doors and protective covers in safety-critical environments. With universal coding and AS-Interface integration, it ensures seamless communication with automation systems. Featuring a maximum retention force of 2600 N, it meets the highest safety requirements, including Performance Level e (Category 4) according to EN ISO 13849-1. Ist robust construction, combined with RFID technology and integrated diagnostics, guarantees reliability and long-term operational safety.

Technical Data:

Product Designation:

• AZM201BZ-ST-T-AS-P

Article Number:

• 103025873

EAN:

• 4030661524313

eCl@ss Numbers:

• Version 12.0: 27-27-26-03
• Version 11.0: 27-27-26-03
• Version 9.0: 27-27-26-03

ETIM Numbers:

• Version 7.0: EC002593
• Version 6.0: EC002593

Approvals and Standards:

• Certifications: TÜV, cULus, Asi-SaW, FCC, IC, ANATEL
• Standards: EN IEC 62026-2, EN ISO 13849-1, EN ISO 14119, EN IEC 60947-5-3, EN IEC 61508

General Data:

• Coding: Universal
• Coding Level: Low (per EN ISO 14119)
• Operating Principle: RFID
• RFID Frequency: 125 kHz
• RFID Transmission Power (Max): -6 dB/m
• Housing Material: Plastic, glass fiber-reinforced thermoplastic
• Reaction Time (Max): 100 ms
• Risk Time (Max): 200 ms
• Gross Weight: 541 g

General Features:

• Closed-Circuit Principle: Yes
• Combined Actuator and Lock Monitoring: Yes
• Latching Function: Yes
• Auxiliary Release: Yes
• Safety Features: Yes
• Integrated Status Indicator: Yes
• Number of Approach Directions: 2

Safety Considerations:

• Performance Level: Up to e
• Category: 4
• PFH Value: 1.81 x 10⁻⁹ /h
• PFD Value: 1.59 x 10⁻⁴
• Safety Integrity Level (SIL): Suitable for SIL 3 applications
• Service Life: 20 years

Mechanical Data:

• Lifespan (Min): 1,000,000 operations
• Retention Force (FZh): 2000 N
• Maximum Retention Force (Fmax): 2600 N
• Latching Force: 30 N
• Actuation Speed (Max): 0.2 m/s
• Fastening Screws: 2x M6
• Screw Tightening Torque (Max): 8 Nm

Connection:

• Connection Type: Embedded M12 Connector, 4-pin, A-coded

Dimensions:

• Length: 50 mm
• Width: 40 mm
• Height: 235.5 mm

Environmental Conditions:

• Protection Class: IP66, IP66
• Operating Temperature: -25 °C to +60 °C
• Storage Temperature: -25 °C to +85 °C
• Relative Humidity: Max 93 % (non-condensing, non-freezing)
• Vibration Resistance: 10–150 Hz, 0.35 mm amplitude
• Shock Resistance: 30 g / 11 ms

Electrical Data:

• Maximum Switch Frequency: 1 Hz
• Auxiliary Voltage (Aux): 24 VDC ±10 %
• AS-Interface Voltage: 26.5–31.6 VDC

AS-Interface Data:

• Safety Slave Specification: AS-i V 3.0
• Profile: S-7.B.F.E
• Inputs: DI 0–DI 3 with dynamic code transmission

Status Indicator (LED):

Green/Red: Supply Voltage, Communication Errors, Device Status

Yellow: Device Status

Red: Fault Detected

Accessories:

Recommended Actuators: AZ/AZM201-B1, AZ/AZM201-B30

Triangular key for auxiliary release included

Note:

Actuator not included in the delivery.

Stabilized PELV power supply required for AUX.

Type: BNS260-02ZG-ST-R
