Rittal 7030140 Monitoring system CMC III analog air flow sensor

Your rating:
Average rating
product review for Rittal 7030140 Monitoring system CMC III analog air flow sensor
( 4.8 / 5 ) 13 ratings
Rittal 7030140
This image may differ from the desired article.
Rittal 7030140Rittal 7030140Rittal 7030140
-22% 295,32 EUR 378,17 EUR
( 351,43 EUR incl. VAT )
≈ £247.18  |  ≈ $324.56
plus delivery charges: 55,00 €
Made to order · Delivery time approx. 5 workdaysinfo_outline
1x Rittal 7030140 Monitoring system CMC III analog air flow sensor
Datasheet:file_download Download
Lieske Part No.:985364
Mfg Part No: 7030140
UPC/EAN: 4028177659520
Weight:0.536 kg
Type:DK 7030140

Product information for Rittal 7030140:

The Rittal DK 7030140 is an analog airflow sensor for the CMC III monitoring system, developed for continuous measurement of air velocity in enclosures, rooms and containers in IT, industrial and building technology applications. The sensor monitors fans, filters and climate control units to provide early warning of changes in airflow or contamination. It connects directly to the CMC III Processing Unit via a CAN-Bus interface, with power supply also provided over the CAN-Bus. Connection is made via RJ45 connectors, enabling a plug-and-play connection with automatic detection and sequential numbering on the bus.

Applications

The sensor is designed for use in IT enclosures, industrial environments and building technology systems. It monitors airflow in enclosed spaces, containers and enclosure environments to ensure the efficiency of ventilation and climate control systems. Applications include monitoring filters to detect contamination levels over time, as well as monitoring fans and climate control units for operational functionality.

Functions and Features in Detail

The sensor operates using the differential temperature measurement method, in which heat loss from the external probe in the airflow is measured to determine air velocity. The probe is attached to the sensor via a cable with connector and must be mounted within the airflow. The measurement range is from 0.5 to 15 m/s. Warning and alarm threshold settings can be configured via the software of the CMC III Processing Unit and are stored directly in the sensor. An integrated multicolored LED status indicator displays the operating status.

Technology Explained Simply

Communication takes place via two RJ45 connectors integrating the CAN-Bus. The sensor has an IP 30 protection rating, while the external airflow probe has an IP 30 rating, making it suitable for use in humid or dusty environments. The operating temperature range is from 0 °C to 55 °C, with relative humidity (non-condensing) from 5 % to 95 %. The housing is made of plastic, with the front in RAL 9005 (black) and the housing in RAL 7035 (gray). Dimensions are 110 mm (width) × 30 mm (height) × 40 mm (depth).

Compatibility and Accessories

The sensor is compatible with various CMC III Processing Units, with the maximum number of participants per system varying: up to 10 participants per IoT Interface, 4 participants with PU compact, 10 participants with PU, and 5 participants with PDU (when powered via PoE). Accessories include CAN-Bus connection cables in various lengths (0.5 m to 10.0 m), as well as Processing Units and PDUs, which can be used to expand the monitoring system.

Mounting and Installation

The sensor is supplied with a mounting plate and fastening materials. The external airflow probe is also included in the delivery and must be installed at the location of the airflow using the provided mounting materials. Installation is performed by direct connection to the CMC III Processing Unit via the CAN-Bus cable, with automatic detection and configuration handled by the system.

Operational Advantages

By integrating airflow measurement and enabling the definition of warning and alarm thresholds, the sensor enables proactive maintenance and optimization of ventilation systems. Power supply over the CAN-Bus reduces the number of required cables and simplifies installation. Automatic detection and plug-and-play functionality reduce commissioning time and installation effort.

General
ModelAnalog air flow sensor
ApplicationsMonitoring of cabinets in IT, industry and building technology. Monitoring of cabinets, rooms and containers in IT environment.
Function principleSettings can be made via the CMC III Processing Unit or via the IoT Interface. The CMC III airflow sensor features an external sensor, mounted in the airflow. By measuring heat loss, the sensor detects airflow and can detect flow fluctuations. Applications: fans, filters, air conditioning units.
MaterialPlastic, front: smooth, housing: textured
ColourFront: RAL 9005, housing: RAL 7035
Scope of deliverySensor, mounting plate, including fastening material, external airflow sensor including mounting material
Connection to CAN busDirect
Interfaces2 x RJ45 CAN-Bus, terminal
Number of participants per IoT interface (max.)10
Number of participants PU compact (max.)4
Number of participants PU (max.)10
Number of PDU participants (max.)5
Number of users per PDU noteMax. 5 units when powered via PoE
Measuring methodDifferential temperature measurement
Width110 mm
Height30 mm
Depth40 mm
Operating temperature range0 °C...55 °C
Humidity (non-condensing)5...95 %
PCF/VE (Cradle-to-Gate)1.6 kg CO2 eq (Cat B)
Note on PCF classCategory B: PCF value (Cradle-to-Gate) approximately calculated based on product weight and self-declared


Product data sheet
Datasheet for Rittal 7030140, EAN: 4028177659520
