Rittal 6501130 Coupling CP 40, steel, for support arm connection 120x65 mm

Your rating:
Average rating
product review for Rittal 6501130 Coupling CP 40, steel, for support arm connection 120x65 mm
( 4.5 / 5 ) 59 ratings
Rittal 6501130
This image may differ from the desired article.
82,80 EUR 86,11 EUR
( 98,53 EUR incl. VAT )
≈ £69.30  |  ≈ $91.00
plus delivery charges: 55,00 €
Delivery time from supplier's stock (ca.) 7 workdaysinfo_outline
In Stock: >100 pieces
1x Rittal 6501130 Coupling CP 40, steel, for support arm connection 120x65 mm
Datasheet:file_download Download
Lieske Part No.:642864
Mfg Part No: 6501130
UPC/EAN: 4028177436053
Weight:1.603 kg
Type:CP 6501130

Product information for Rittal 6501130:

The Rittal CP 6501130 is a housing coupling of type CP 40, specifically designed for the rotatable mounting of enclosures or housings on the vertical part of the support arm system 40. The product serves as a connecting element between the enclosure and the support arm, enabling a flexible installation that allows adaptation to different angles and positions during operation. The coupling is made of zinc die-cast, ensuring high mechanical stability and durability, especially in industrial environments with high loads. The surface is coated with a structured lacquer, forming a robust protective layer against corrosion and mechanical stress. The colour corresponds to the standard RAL 7024, a dark grey tone that integrates well in industrial facilities.

Applications

The coupling is primarily used in industrial electrical engineering and automation technology, where enclosures or electronic housings are mounted on support arms. It is particularly suitable for installations requiring flexible positioning of the housing, such as in production lines, machine controls, or process automation. The rotatable mounting allows optimal alignment of the housing to make operating elements, displays, or cable connections more accessible.

Functions and Equipment in Detail

The coupling is rotatable/tiltable and offers a rotational angle/swivel range of approx. 305°, ensuring extensive freedom of movement. The position can be fixed using a clamp lever, which allows secure and stable fixation in the desired position. This is particularly advantageous when the housing should not be moved after installation but requires flexible alignment during installation or maintenance. The coupling is designed for a support arm connection of 120 x 65 mm, ensuring an exact fit with the support arm system CP 40.

Technology Explained Simply

The use of zinc die-cast as material ensures high strength with low weight. The structured lacquer provides additional protection against environmental influences such as moisture, dust, or mechanical wear. The rotational function is enabled by an integrated joint that can be locked via the clamp lever. This design ensures that the housing does not move unintentionally during operation, but can be easily re-aligned if needed. The specification of approx. 305° means that the coupling allows almost a full circle, with the remaining 55° limited by the mechanical construction.

Compatibility and Accessories

The coupling is specifically developed for the support arm system CP 40 and fits exactly onto the vertical support arms with dimensions 120 x 65 mm. It is therefore compatible with all enclosures and housings connected to this system.

Mounting and Installation

Installation is carried out by simply attaching the coupling to the support arm and then securing the enclosure to the coupling. The rotatable function is activated and fixed using the clamp lever. The installation requires no special tools or additional components, as the coupling itself provides the necessary connection.

Advantages in Operation

The rotatable mounting allows optimal alignment of the enclosure, simplifying operation and maintenance. Fixation via the clamp lever ensures secure positioning that remains stable even under operating conditions. The material choice of zinc die-cast and structured lacquer ensures high service life and resistance to industrial loads. The coupling is thus a reliable component for flexible mounting of enclosures in industrial facilities.

General
Materialzinc die-cast
Surface protectionStructured lacquer
ColourRAL 7024
Rotation angle/tilt rangeapprox. 305°, lockable via clamp lever
Rotatable/tiltableJa


Product data sheet
Datasheet for Rittal 6501130, EAN: 4028177436053

Questions & answers

What is the delivery time of Rittal 6501130 Coupling CP 40, steel, for support arm connection 120x65 mm?

The article Rittal 6501130 Coupling CP 40, steel, for support arm connection 120x65 mm is currently in stock

According to our experience the article is ready for dispatch within 7 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Rittal 6501130 to our sales team for an exact delivery time.

How can I buy the item at a lower price?

We offer you Rittal 6501130 Coupling CP 40, steel, for support arm connection 120x65 mm always at the best possible price. We can give you a discount of 2% on Rittal 6501130 Coupling CP 40, steel, for support arm connection 120x65 mm if you choose payment in advance on ordering.

We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
