Rittal 3237708 Blue e+ filter fan 20/25 m³/h, 230 V, RAL 9005
|
62,68 EUR |
|
|
( 74,59 EUR incl. VAT ) ≈ £52.46 | ≈ $68.89 plus delivery charges: 55,00 € |
|
| Delivery time from supplier's stock (ca.) 12 workdaysinfo_outline | |
| In Stock: >100 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 683779 |
| Mfg Part No: | 3237708 |
| UPC/EAN: | 4028177998308 |
| Weight: | 0.468 kg |
| Type: | SK 3237.708 |
Product information for Rittal 3237708:
Applications
The filter fan is suitable for use in industrial environments where continuous and reliable ventilation of enclosures is required. It is commonly used in machine building, automation technology, and plant engineering to ensure operational safety of electronic components through heat dissipation. The integrated non-woven filter mat ensures that dust and particles are filtered from the incoming air, reducing contamination of enclosure components.
Functions and equipment in detail
The fan features diagonal fan technology, providing higher pressure stability and thus enabling more uniform and consistent air circulation within the enclosure. The diagonal exhaust direction ensures better distribution of airflow, leading to more efficient cooling of devices inside. The fan is an axial fan with a slot-pole motor, designed for reliable and quiet operation. The air performance is 20 m³/h free blowing at 50 Hz and 25 m³/h at 60 Hz. When using an additional outlet filter, the air performance reduces to 15 m³/h (50 Hz) or 18 m³/h (60 Hz). The electrical connection is made via two individual conductors, each approximately 300 mm in length, connected directly to the unit.
Technology explained simply
The protection rating IP 54 is achieved standard when the fan operates with the non-woven filter mat. When using an additional spray water hood, the protection rating increases to IP 56, offering higher protection against dust and splashing water. According to NEMA standards, the protection rating corresponds to Type 12 with non-woven filter and Type 3, 3R with non-woven filter and spray water hood. The operating temperature ranges from -15 °C to 55 °C, and the storage temperature from -30 °C to 70 °C. The sound pressure level is 42 dB(A) at 50 Hz and 47 dB(A) at 60 Hz, indicating quiet operation. The rated power is 13 W at 50 Hz and 11.1 W at 60 Hz, with a maximum rated current of 0.1 A and 0.09 A respectively. A fuse with 2 A is provided to protect the fan against overloads.
Compatibility and accessories
The fan can be combined with various accessories to extend functionality and protection class. These include the Blue e+ outlet filter in RAL 9005, which reduces air performance but increases filtration efficiency. A spray water hood for SK 3237.xxx stainless steel can be used to increase the protection rating to IP 54 and NEMA Type 3/3R. Further options include a thermostat for internal temperature control, a speed controller for adjusting fan speed, a digital temperature display and control, and a hygrostat for humidity control. A blind cover is available to close mounting cutouts, and a non-woven filter mat can be used as a replacement filter.
Mounting and installation
Mounting is tool-free via optimised snap hooks, enabling quick and secure attachment to the enclosure. The standardised mounting cutout of 92 mm in width and height fits common enclosure constructions. The installation depth of 46 mm ensures the fan can be mounted flush into the enclosure wall without significantly protruding from the outer surface.
Advantages in operation
The fan provides a reliable and low-maintenance ventilation solution. The easy filter replacement is enabled by a new opening mechanism on the louver grille, simplifying maintenance. The tool-free mounting reduces installation time. The diagonal fan technology ensures even air distribution, increasing cooling efficiency. The integrated non-woven filter mat protects enclosure components from contamination, extending the lifespan of electronic components. The operating voltage of 230 V, 1~, 50 Hz/60 Hz makes the fan universally applicable in various countries and power networks.
The delivery includes a fully ready-to-install unit including non-woven filter mat.
| General | |
| Model | Wall surface mounted |
| Material | Plastic |
| Colour | RAL 9005 |
| Scope of delivery | Complete ready-to-install unit, including felt filter mat |
| Fan | Axial, split-pole motor |
| Airflow free-blowing (with filter) | At 50 Hz: 20 m³/h, At 60 Hz: 25 m³/h |
| Airflow with associated exhaust filter including felt filter | At 50 Hz: 15 m³/h, at 60 Hz: 18 m³/h |
| Rated operating voltage | 230 V, 1~, 50 Hz/60 Hz |
| Rated power Pel | At 50 Hz: 13 W, At 60 Hz: 11.1 W |
| Rated current max. | At 50 Hz: 0.1 A, At 60 Hz: 0.09 A |
| Width | 116,5 mm |
| Height | 116,5 mm |
| Depth | 64,5 mm |
| Built-in depth | 46 mm |
| Mounting cutout | Cutout width: 92 mm, cutout height: 92 mm |
| Degree of protection IP according to IEC 60 529 | IP 54 with felt filter, IP 56 with felt filter and spray hood |
| NEMA degree of protection | Type 12 with felt filter, Type 3, 3R with felt filter and spray water hood |
| Fuse | Circuit breaker/fuse: 2 A |
| Note | For the filter fan 3237.XXX, the electrical connection is made via 2 individual wires (approx. 300 mm length) on the device; for all other filter fans, via spring clamp terminal. |
| Operating temperature range | -15 °C...55 °C |
| Storage temperature range | -30 °C...70 °C |
| Sound pressure level | At 50 Hz: 42 dB(A), At 60 Hz: 47 dB(A) |
