Rittal 3114200 SK Digital temperature display and thermostat, 100-230 V, 1~, 50/60 Hz, 24-60 V (DC), Installation depth: 100 mm
|
89,11 EUR 92,79 EUR |
|
|
( 106,04 EUR incl. VAT ) ≈ £76.55 | ≈ $102.12 plus delivery charges: 53,00 € |
|
| Delivery time from supplier's stock (ca.) 5 workdaysinfo_outline | |
| In Stock: 4 pieces | |
| Lieske Part No.: | 502047 |
|---|---|
| Mfg Part No: | 3114200 |
| UPC/EAN: | 4028177631434 |
| Weight: | 0.123 kg |
Further Rack-Climatization from RittalFurther products in category Rack-Climatization
All products of Rittal
Product information for Rittal 3114200:
For installation in the enclosure door or wall.
Technical specifications: Three-digit, 7-segment display
Option of switching between °C/°F
Includes 1800 mm long NTC sensor
Two relay outputs as change-over contact and normally open contact (max. contact load 230 V, 6 A)
Freely selectable switching difference
Protection category IP to IEC 60 529: IP 54
Packs of: 1 pc(s).
EAN: 4028177631434
Customs tariff number: 90268020
eCl@ss 5.1: 27180792
eCl@ss 7.0: 27210707
ETIM 6.0: EC002014
Rated operating voltage: 100 V - 230 V, 1~, 50 Hz/60 Hz
24 V - 60 V (DC)
Installation depth: 100 mm
Temperature range: Operation (environment): +0°C...+50°C
Setting range: +5°C...+55°C
Weight/pack: 0.26 kg
Type: SK 3114200
Technical specifications: Three-digit, 7-segment display
Option of switching between °C/°F
Includes 1800 mm long NTC sensor
Two relay outputs as change-over contact and normally open contact (max. contact load 230 V, 6 A)
Freely selectable switching difference
Protection category IP to IEC 60 529: IP 54
Packs of: 1 pc(s).
EAN: 4028177631434
Customs tariff number: 90268020
eCl@ss 5.1: 27180792
eCl@ss 7.0: 27210707
ETIM 6.0: EC002014
Rated operating voltage: 100 V - 230 V, 1~, 50 Hz/60 Hz
24 V - 60 V (DC)
Installation depth: 100 mm
Temperature range: Operation (environment): +0°C...+50°C
Setting range: +5°C...+55°C
Weight/pack: 0.26 kg
Type: SK 3114200
Questions & answers
What is the delivery time of Rittal 3114200 SK Digital temperature display and thermostat, 100-230 V, 1~, 50/60 Hz, 24-60 V (DC), Installation depth: 100 mm?
The article Rittal 3114200 SK Digital temperature display and thermostat, 100-230 V, 1~, 50/60 Hz, 24-60 V (DC), Installation depth: 100 mm is currently in stock
According to our experience the article is ready for dispatch within 5 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Rittal 3114200 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Rittal 3114200 SK Digital temperature display and thermostat, 100-230 V, 1~, 50/60 Hz, 24-60 V (DC), Installation depth: 100 mm always at the best possible price. We can give you a discount of 2% on Rittal 3114200 SK Digital temperature display and thermostat, 100-230 V, 1~, 50/60 Hz, 24-60 V (DC), Installation depth: 100 mm if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
