Planet Industrial 24-Port PoE+ Managed Switch IGS-6325-24UP4
|
1.057,60 EUR |
|
|
( 1.258,54 EUR incl. VAT ) plus delivery charges |
|
| Delivery time on requestinfo_outline | |
| Lieske Part No.: | 1196983 |
|---|---|
| Mfg Part No: | IGS-6325-24UP4X |
| UPC/EAN: | 4711605287180 |
| Weight: | 4.9 kg |
Product information for Planet IGS-6325-24UP4X:
High-Power PoE++ L3 Industrial Switch with 24 Ports and 10G Uplink
The PLANET IGS-6325-24UP4X is a rugged, high-performance Layer 3 Managed Industrial Switch designed for heavy-duty PoE++ applications. It offers 24 802.3bt Type-4 PoE++ ports, each delivering up to 95W, and 4 10G SFP+ uplink ports, all packed in a 1U rackmount chassis. With a total PoE budget of up to 1440W, it’s ideal for powering power-hungry devices such as PTZ cameras, thin clients, PoE lighting, and digital signage systems.
Advanced Layer 3 routing (OSPFv2/v3, RIP), ERPS ring redundancy, comprehensive security features, and intelligent PoE management tools ensure efficient and stable operation even in -40 to +75°C environments.
Technical Details (English):
Interfaces:
- 24 x 10/100/1000BASE-T RJ45 PoE++ ports (up to 95W each)
- 4 x 10GBASE-SR/LR SFP+ ports (1G/2.5G compatible)
- 1 x RJ45-to-RS232 console port
PoE++ Power Features:
- IEEE 802.3bt Type-4 compliant, backwards compatible with 802.3af/at
- Max. power: 95W per port
- Total power budget: 720W (single input), 1440W (dual input)
- PoE Management: scheduling, PD alive check, priority, power recycling
Layer 3 Routing:
- Static/dynamic routing (IPv4/IPv6)
- OSPFv2/v3, RIPv2 support
- Up to 128 routes, 4K hardware table entries
Layer 2 Switching:
- VLAN: 802.1Q, Q-in-Q, Private VLAN, Voice, MAC/Protocol-based
- Link Aggregation: 14 trunks, 16 ports per group, up to 104Gbps
- STP/RSTP/MSTP, BPDU Guard, Loop protection
- Multicast: IGMP/MLD Snooping, MVR, Querier
- QoS: 8 queues, DSCP, CoS, WRR/Strict Priority
- Bandwidth Control: 10Kbps to 13Gbps per port
Security:
- 802.1X, MAC auth, Guest VLAN
- RADIUS/TACACS+ integration
- IP/MAC ACLs (up to 512 rules)
- DHCP Snooping, ARP Inspection, IP Source Guard
Alarm & Monitoring:
- 2 Digital Inputs / 2 Digital Outputs
- Alarm relay: 3A @ 24V DC
- SFP-DDM, SNMP traps, remote syslog
- Modbus TCP, IEEE 1588 PTPv2 (transparent clock), LLDP
Management:
- Web GUI (HTTP/HTTPS), Telnet, CLI, SNMP v1/v2c/v3
- Secure: SSHv2, TLSv1.2
- Utilities: PLANET Smart Discovery, CloudViewer, UNI-NMS
- Firmware upgrade, dual images, DHCP/TFTP/NTP supported
Mechanical Design:
- Metal IP30 case, fanless design
- Size: 443.7 x 301.5 x 44 mm
- Weight: 4.05 kg
- Rack-mountable (1U)
- Operating Temp: -40 to +75°C
- Power: Dual 48~54V DC input, up to 32A
- Power Draw: Max. 1.52kW full load
Application Scenarios:
- Industrial Automation
- IP Surveillance and Access Control
- Wireless Infrastructure (High-density APs)
- Smart Buildings & Digital Signage
Questions & answers
What is the delivery time of Planet Industrial 24-Port PoE+ Managed Switch IGS-6325-24UP4?
The article Planet Industrial 24-Port PoE+ Managed Switch IGS-6325-24UP4 is currently not in stock und muss auftragsbezogen bestellt werden.
According to our experience the article is ready for dispatch within 16 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Planet IGS-6325-24UP4X to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Planet Industrial 24-Port PoE+ Managed Switch IGS-6325-24UP4 always at the best possible price. We can give you a discount of 2% on Planet Industrial 24-Port PoE+ Managed Switch IGS-6325-24UP4 if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
