GRP cable tray, pressed, with unperforated side rails, with molded connector, with transverse reinforcements (5 mm) over the entire cable tray width and fifteen rows of fastening holes in the base, mechanical strength in accordance with IEC 61537, please order corresponding fastening accessories separately, halogen-free. Due to the transverse reinforcements, the cable tray is also approved for use with high-frequency cables in accordance with UTE C15-900 (application class D, frequency 16 MHz). An expansion distance of 8 mm must be taken into account. Due to the expansion of the material, the following must be observed during assembly: - The cable tray should not be screwed close to or at the joint. - When screwing the cable tray onto the brackets, a through hole of Ø 9 mm for the FKM 6X20 E4 screws must always be made in the tray. Article also available in ...AC (resin mixture with acrylic resin). Dimensions (approx. dimensions) H x W : 80 x 400 mm Material thickness t : 4 mm Bottom bead shape : 60 x 5 mm Bottom bead shape Grid dimension : 313 mm Bottom perforation : 9 x 20 mm Row spacing : 25 mm Bottom hole spacing Grid dimension : 313 mm Load capacity F at a support spacing of 1.5 m : 1 kN/m Delivery length : 3000 mm Usable cross-section : 27720 mm² Material : UP-GF (glass fiber reinforced polyester) Color : pebble gray RAL : 7032 (similar)
Type: KKL 80.400
The item price shown refers to 3 meters Niedax KKL80.400
Please note...
This article has over-size and needs to be seperately taken care of. This is why we want to inform you, that the calculation of the delivery charges in the shopping cart will disregard this aspect. Though, there will be corresponding surcharges after you send us your order.
Questions & answers
What is the delivery time of Niedax KKL80.400 KKL 80,400 GRP cable tray, KKL 80,400?
The article Niedax KKL80.400 KKL 80,400 GRP cable tray, KKL 80,400 is currently
not in stock but has been backordered.
According to our experience the article is ready for dispatch within 9 working days.
The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time.
Just send us an inquiry about the desired quantity of Niedax KKL80.400 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Niedax KKL80.400 KKL 80,400 GRP cable tray, KKL 80,400 always at the best possible price. We can give you a discount of 2% on
Niedax KKL80.400 KKL 80,400 GRP cable tray, KKL 80,400 if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
How many units does the article contain?
Niedax KKL80.400 KKL 80,400 GRP cable tray, KKL 80,400 is offered by us in a sales unit of 3 meters If you need a larger quantity, you can contact us at any time. We will make a special offer for you
