Netgear Manageable Ethernet Switch - 2 Layer Supported content_copy

The NETGEAR M4300 Stackable Switch Series delivers L2/L3/L4 and IPv4/IPv6 cost-effective services for mid-enterprise edge with full PoE+ and SMB core deployments with unrivalled ease of use: 10 Gigabit models can seamlessly stack with 1 Gigabit models within the series, enabling spine and leaf line-rate stacking topologies. Non-stop forwarding (NSF) virtual chassis architectures provide advanced High Availability (HA) with hitless failover across the stack. Dual redundant, modular power supplies equipping full width models contribute to business continuity management. Layer 3 feature set includes static, dynamic and policy-based routing - as standard. Perfect for wireless access, unified communications and IP video, the NETGEAR M4300 Switch Series is also ready for the future, with Software-defined Network (SDN) and OpenFlow 1.3 enabled for your network. Best-in-class stacking
M4300 is flexible enough for mixed stacking between 10 Gigabit and 1 Gigabit models, using any 10G port with any media type (RJ45, SFP+, DAC cables) High-availability is another key differentiator for stackable solutions: in case of a master switch failure, NSF and hitless failover ensure the standby switch takes over while forwarding plane continues to forward traffic on the operational stack members without any service interruption Higher flexibility
Two half-width M4300 switches can be paired in a single rack space for redundant Top of Rack installations with Auto-iSCSI prioritization 10 Gigabit ports are all independent and 1G backward compatible for progressive transition to 10G speeds Lower complexity
Entire feature set including L2 switching (multi-tiered access control) and L3 routing (static, RIP, OSPF, VRRP, PIM, PBR) is available without license DHCP/BootP innovative auto-installation including firmware and configuration file upload automation Investment protection
Line-rate spine and leaf stacking topologies offer multiple possibilities in server rooms, in branch collapsed cores or at the edge of growing networks Even if an organization is not ready for SDN, OpenFlow support offers future-ready design for maximum investment protection Secure services
With successive tiering, the Authentication Manager allows for authentication methods per port for a tiered authentication based on configured time-outs With BYOD, tiered Dot1x ->; MAB ->; Captive Portal authentication is powerful and simple to implement with strict policies Industry standard management
Industry standard command line interface (CLI), functional NETGEAR web interface (GUI), SNMP, sFlow and RSPAN Single-pane-of-glass NMS300 management platform with centralized firmware updates and mass-configuration support Industry leading warranty
NETGEAR M4300 series is covered under NETGEAR ProSafe Lifetime Hardware Warranty 90 days of Technical Support via phone and email, Lifetime Technical Support through online chat and Lifetime Next Business Day hardware replacement

Data transmission
Switching capacity	320 Gbit/s
Forwarding rate	357 Mpps
MAC address table	16000 entries
Number of static routes	64
Jumbo frames	9000
Store-and-forward
Jumbo frames support
Design
Form factor	1U
Product colour	Black
LED indicators	Activity, Power, Speed
Safety	CSA 22.2 #950, UL 1950)/cUL IEC 950/EN 60950
Electromagnetic compatibility	CE, FCC 15 A, VCCI A, A EN 55022, (CISPR 22) A, EN 50082-1, EN 55024
Rack mounting
Stackable
Logistics data
Harmonized System (HS) code	85176990
Management features
Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support
Web-based management
ARP inspection
Multicast features
Number of multicast groups filtered	4000
Multicast support
Network
Networking standards	IEEE 802.11ad, IEEE 802.11az, IEEE 802.3ad, IEEE 802.3az
Cable types supported	Cat5, Cat5e, Cat6, Cat7
Virtual LAN features	Private VLAN
10G support
Port mirroring
IP routing
Flow control support
Link aggregation
Rate limiting
Auto MDI/MDI-X
Spanning tree protocol
Auto-sensing
Auto-negotiation
VLAN support
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-20 - 70 °C
Operating relative humidity (H-H)	0 - 90%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 3000 m
Heat dissipation	18577 BTU/h
Optical fiber
Fiber ethernet cabling technology	10GBASE-LR, 10GBASE-LRM, 10GBASE-SR
Packaging content
Cables included	AC, LAN (RJ-45), Mini-USB
User guide
Rack mount kit
Packaging data
Rubber feet
Resource CD
Performance
Processor frequency	800 MHz
Internal memory	1024 MB
Flash memory	256 MB
Noise level	36.9 dB
Mean time between failures (MTBF)	196120 h
Built-in processor
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	8
Basic switching RJ-45 Ethernet ports type	10G Ethernet (100/1000/10000)
SFP+ module slots quantity	8
Fiber optic connector	SFP+
Console port	RJ-45/Mini-USB
USB 2.0 ports quantity	1
Power
Number of power supply units	1
AC input voltage	120 - 230 V
Power consumption (max)	49 W
Power supply included
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Security
DHCP features	DHCP server, DHCP client
Security algorithms	HTTPS, SNMP, SSH
Access Control List (ACL)
SSH/SSL support
BPDU filtering/protection
Weight & dimensions
Width	212 mm
Depth	345 mm
Height	44 mm
Weight	3.32 kg

---
