Microsens installation switch GBE 6 port, vert. installation, 5xRJ45, 1xST duplex, PoE+, MS440213PM-48G6+

Microsens installation switch GBE 6 port, vert. installation, 5xRJ45, 1xST duplex, PoE+, MS440213PM-48G6+
GBE installation switch 4x10/100/1000Base-T + PoE/PoE+, uplink: 1x1000Base-LX, ST monomode 1310 nm, downlink: 1x10/100/1000Base-T + PoE+ vertical installation, 44..57 VDC power supply, 5x RJ-45, 1x SC duplex, 1x 3-pin DCThe MICROSENS 6-Port GbE Micro Switch G6 is a compact, high-performance network switch specifically designed for Fiber-To-The-Office applications. Offering a variety of configurations tailored to individual customer needs, the switch provides flexible customization options. Equipped with up to two fiber uplink ports and optional PoE+ functionality, this switch is ideal for modern IT environments.

The Micro Switch G6 is available in both horizontal and vertical form factors, ensuring maximum flexibility during installation. With a switching capacity of 32 Gbps, full wire-speed performance, and a MAC address table supporting up to 8,192 entries, the switch delivers fast and reliable data transfer. Additionally, it supports the IEEE 802.3az standard for energy-efficient Ethernet, dynamically adjusting power consumption based on network load.

Optional PoE+ models deliver up to 30 W per port with a total maximum output of 80 W, making them perfect for powering IP cameras, access points, or other network devices. Moreover, the Linux-based operating system enables easy management via web interface, SNMP, or CLI scripts. The robust, fanless design and straightforward snap-in mounting make the switch a durable, low-maintenance solution for diverse installation environments such as trunking channels, floor tanks, or surface-mounted housings.

Technical details:

Type:

• Gigabit Ethernet Switch (Layer-2+), Store-and-Forward

Performance:

• Switching capacity: 32 Gbps
• MAC addresses: 8,192, automatic learning and aging
• Jumbo frames: up to 10,240 bytes

Ports:

• Local ports: 4 or 5x RJ-45 (10/100/1000Base-T)
• Uplink ports: 1 or 2x fiber ports (1000Base-SX/-LX) or SFP (100/1000Base-X)
• PoE+: IEEE 802.3at, max. 30 W/port, max. 80 W total output

Network management:

• Web manager (HTTP/HTTPS), Telnet/SSH
• SNMP v1/v2c/v3, IPv4/IPv6 dual stack
• CLI script support
• Firmware and configuration updates via FTP/SFTP/TFTP

Power supply:

• PoE variant: 54 V DC, max. power consumption 80 W
• Non-PoE variant: 230 V AC, typical power consumption 4.5 W

Mounting:

• Snap-in mounting for 45 mm installation systems
• Compatible with standard trunking channels and floor tanks

Dimensions & weight:

• Dimensions: 90 x 45 x 59.7 mm (L x W x H, without connectors)
• Weight: 325 g

Operating conditions:

• Operating temperature: 0 to 40 °C
• Storage temperature: -20 to 85 °C
• Humidity: 10–90%, non-condensing

Scope of delivery:

• 1x Micro Switch G6
• 1x Grounding cable (PE)
• 1x Power supply connector
• 1x Quick start guide
• 1x Set of pictogram stickers

Key features:

• Supports up to 2 independent ring topologies
• Enhanced security and data integrity with optional microSD memory card

Applications:

• Office and industrial networks
• Integration into trunking channels, floor tanks, or surface-mounted housings
• Power-over-Ethernet for powering network devices

Quality:

• Manufactured in Germany with strict quality controls and burn-in tests
• Reliability through robust design and long service life
